Denon AVR-X2100W Service Manual

YES
YES
YES
YES
Check the TV.
(11) Does the TV support HDCP?
(13) Is HDMI input set on the TV?
(14) Are a picture and sound output when a different TV is used?
Check the unit.
Check the rmware.
Is "
IP SCALER NG
" displayed?
(See 23 page)
(12) Does the TV support 1080P?
Use a TV that supports HDCP. Computer monitors can-
not be used.
Check the instruction manual of the TV and check the
input setting.
The TV is faulty.
•Check the circuits around the IP SCALER (U1026,
HDMI PCB) and DDR2 (U1028/1029).
If there appear to be no problems, U1026 or U1028/1029
is faulty.
If the TV does not support 1080P, a picture cannot be
output even if the Blu-ray/DVD player is set to 1080P.
NO
NO
NO
YES
NO
See "AVR-X2100W-S900_HDMI Rx-Tx Failure Detection Procedure
Manual ver_1.00" of SDI.
NO
86

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
