Denon AVR-X2100W Service Manual

Input
COMPONENT
C
Check the set value of each
IC. Are the voltage values as
follows?
HDMI PCB
N1018 - 2pin : Lo(0V)
N1018 - 6pin : Hi(3.3V)
Is the power supply voltage
being output correctly?
V+5V : C5029 : + side
V-5V : C5031 : - side
Is a signal being output from
the video amplier?
COMP-Y : J5032
COMP-CB : J5033
COMP-CR : J5000
The circuit between IC5002
and JACK5000 are faulty.
Use the jigs to extend the
HDMI PCB.
The HDMI PCB is faulty.
Check the connection between the
FRONT CONNECTOR PCB and the
VIDEO PCB.
NO
NO
NO
YES
YES
YES
b
All parts are VIDEO PCB parts unless otherwise specied.
w
q
e
r
•Check the IC5001 power supply voltage and check the soldering of the surround-
ing circuits.
•The circuit between IC5002 and JACK5000 are faulty.
•Check the cable between the unit and the player, and check the player itself.
84

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
