Denon AVR-X2100W Service Manual

Connect the connectors correctly.
Repair the HDMI PCB.
NO
YES
4.3. Analog audio
No audio output.
Is a voltage of ±7V supplied to INPUT
PCB CN4006?
Is there an audio signal in INPUT
PCB CN401?
Is electron volume serial data being
sent to INPUT PCB CN4200?
Once more, connect the connectors correctly.
If the malfunctioning channel and function can be identied, check the corresponding
signal path.
Repair the ±7V power supply.
Repair the power amplier.
Is the connector correctly connected
with HDMI PCB?
YES
NO
YES
NO
YES
NO
89

Denon AVR-X2100W Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	150 W
Power output per channel (20-20KHz@8 Ohm)	95 W
HDMI in	8
Composite video in	2
Component video (YPbPr/YCbCr) in	1
Speakers connectivity type	-
Ethernet LAN	Yes
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Optical drive included	No
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	500 W

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	167 mm
Weight	9700 g
