Denon AVR-X2200W Service Manual

VIDEO
VIDEO PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
IC5001 963235100700S NJM2595M-TE1 DMP16 5-INPUT 3-OUTPUT VIDEO SWITCH J171259500010S 1
IC5002 963235100630S NJM2586AVC3 VIDEO SWITCH SSOP20-C3 J171258600020S 1
Q4219 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
RESISTOR GROUP
R5007,5008 nsp 75-J,1/16W-1608REEL C20007506M160S 2
R5009,5010 nsp 10K-J,1/16W-1608REEL C20001036M160S 2
R5011 nsp 75-J,1/16W-1608REEL C20007506M160S 1
R5014 nsp 75-J,1/16W-1608REEL C20007506M160S 1
R5015 nsp 150-J,1/16W-1608REEL E3, S910 C20001516M160S 1
R5016 nsp 150-J,1/16W-1608REEL C20001516M160S 1
R5017 nsp 160-J,1/16W-1608REEL E3, S910 C20001616M160S 1
R5018 nsp 160-J,1/16W-1608REEL C20001616M160S 1
R5019 nsp 150-J,1/16W-1608REEL E3, S910 C20001516M160S 1
R5020 nsp 150-J,1/16W-1608REEL C20001516M160S 1
R5021 nsp 160-J,1/16W-1608REEL E3, S910 C20001616M160S 1
R5022 nsp 160-J,1/16W-1608REEL C20001616M160S 1
R5023 nsp 150-J,1/16W-1608REEL E3, S910 C20001516M160S 1
R5024 nsp 150-J,1/16W-1608REEL C20001516M160S 1
R5025 nsp 160-J,1/16W-1608REEL E3, S910 C20001616M160S 1
R5026 nsp 160-J,1/16W-1608REEL C20001616M160S 1
R5033-5035 nsp 75-J,1/16W-1608REEL C20007506M160S 3
R5036 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R5037-5039 nsp 75-J,1/16W-1608REEL E3, S910 C20007506M160S 3
R5069-5071 nsp 10K-J,1/16W-1608REEL E2, E1C, JP C20001036M160S 3
CAPACIITORS GROUP
C5008-5010 nsp COG68PF-J/50V-1608REEL E3, S910 D010680167160S 3
C5011 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5012 nsp COG68PF-J/50V-1608REEL D010680167160S 1
C5013,5014 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C5015,5016 nsp COG68PF-J/50V-1608REEL D010680167160S 2
C5017,5018 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 2
C5019,5020 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 2
C5021 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C5022 00D9630293709 100UF-M/10V,5*11-5RE.SMS SY D040101082070S 1
C5023-5025 00D9630293602 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) E3, S910 D040010087150S 3
C5026,5027 00D2544573981 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 2
C5029 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C5030 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C5031 00D2544574922 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C5032 nsp X7R)0.1UF-K/50V-1608REEL D011104577160S 1
C5048 963133502380S MI-0.1UF-J/100V-5RE HMM104J2AP050T DAEHUNG D02010416C250S 1 *
C5051 963133502380S MI-0.1UF-J/100V-5RE HMM104J2AP050T DAEHUNG D02010416C250S 1 *
OTHER PARTS GROUP
BKT5001,5002 nsp AVRX2200WBKE3(DENON) BURRING HOLE SPCC t0.8+SN A4/ 4010210196100SV 2 *
BKT5003 nsp AVRX2200WBKE3(DENON) BURRING HOLE SPCC t0.8+SN A4/ E2, E1C, JP 4010210196100SV 1 *
CLAMP300 nsp HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CN4002 nsp 1.25B-2-15Y 15P BtoB SOCKET(FEMALE) P=1.25MM L109125421510S 1
CN4003 nsp 1.25B-2-19Y 19P BtoB SOCKET(FEMALE) P=1.25MM L109125421910S 1 *
CN5000 nsp 1.25B-2-21Y 21P BtoB SOCKET(FEMALE) P=1.25MM L109125422110S 1
CN5003 nsp 1.25B-2-11Y 11P BtoB SOCKET(FEMALE) P=1.25MM L109125421110S 1
CP3401 nsp 1.25B-2-25A 25P BtoB HEADER(MALE) P=1.25MM L109125322510S 1 *
CP5000 nsp 1.25B-2-21A 21P BtoB HEADER(MALE) P=1.25MM L109125322110S 1
CP5003 nsp YMAW025-08R DIP RA L102025080010S 1
! F5006 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F5006A nsp PI5.2-REEL G645000050010S 1
F5006B nsp PI5.2-REEL G645000050010S 1
! F5007 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F5007A nsp PI5.2-REEL G645000050010S 1
F5007B nsp PI5.2-REEL G645000050010S 1
! F5008 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F5008A nsp PI5.2-REEL G645000050010S 1
F5008B nsp PI5.2-REEL G645000050010S 1
! F5009 963652010500S T1.6A/250V-IVBSUCPCcUR S506 N751501601160S 1
F5009A nsp PI5.2-REEL G645000050010S 1
F5009B nsp PI5.2-REEL G645000050010S 1
JACK5000 00D9630257004 RCA-206B-01(YL,YL) G601206B0100YS 1
JACK5001 963643101630D RCA-303B1-08(GN,BL,RD) E3, S910 G606303B1080YS 3
JACK5002 963643101630D RCA-303B1-08(GN,BL,RD) G606303B1080YS 3
JACK5003 963643101630D RCA-303B1-08(GN,BL,RD) E3, S910 G606303B1080YS 3
5

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
