Denon AVR-X2200W Service Manual

INPUT
INPUT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model JP : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D4210-4212 00D2760401905 1SS133-DO34-AXIAL LRC K000013300040S 3
D4213,4214 963201500160D 1N4007 52REEL 1000V 1A K000400700220S 2
IC4200 963235100750S BD34704KS2 SQFP-T80C 7.1CH SOUND PROCESSOR J084347040010S 1 *
IC5201 963232100450S NJM4580CG SOP8 E3, E2, E1C, JP J121458000050S 1 *
Q4204 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
Q4205 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4206,4207 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 2
Q4208 943216500020S RT1N141C 0.2W/SC-59 ISAHAYA J522101411210S 1
Q4209 943215500020S RT1P141C 0.2W/SC-59 ISAHAYA J520101411210S 1
U1047 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1049 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1051 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
U1053 963232100390S NJM8080G SOP8 DUAL OP AMP J121808000010S 1
ZD4200 963202500290D ZJ3.6B-0.5W/5MA-52MM SEMTECH K06003R644522S 1
RESISTOR GROUP
R1999 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2000 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2001 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2002 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2003 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2005,2006 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2009 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R2010 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2011 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2012 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2013 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2014 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2015 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R2017 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2018 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2019 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2021 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2022 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2024,2025 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2030 nsp 150K-J,1/16W-1608REEL C20001546M160S 1
R2031 nsp 30K-J,1/16W-1608REEL C20003036M160S 1
R2034 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2035 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2036 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2038 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2039 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2040 nsp 30K-J,1/16W-1608REEL C20003036M160S 1
R2041 nsp 150K-J,1/16W-1608REEL C20001546M160S 1
R2044 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2045 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2046 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2047 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2048 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2051,2052 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2056 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R2058 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2059 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2060 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2062 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2063 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2064 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R2069 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2070 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2071 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2072 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2073 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2076,2077 nsp 11K-J,1/16W-1608REEL C20001136M160S 2
R2081 nsp 11K-J,1/16W-1608REEL C20001136M160S
1
R2082 nsp
15K-J,1/16W-1608REEL C20001536M160S 1
R2083 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2084 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R2085 nsp 15K-J,1/16W-1608REEL C20001536M160S 1
R2086 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R2087 nsp 11K-J,1/16W-1608REEL C20001136M160S 1
R4216,4217 nsp 91K-J,1/16W-1608REEL C20009136M160S 2
R4218-4221 nsp 91K-J,1/16W-1608REEL C20009136M160S 4
R4240 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4241 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4244,4245 nsp 470K-J,1/16W-1608REEL C20004746M160S 2
R4248 nsp 100-J,1/16W-1608REEL C20001016M160S 1
R4255-4258 nsp 100-J,1/16W-1608REEL C20001016M160S 4
R4259-4262 nsp 100K-J,1/16W-1608REEL C20001046M160S 4
R4263-4270 nsp 10K-J,1/16W-1608REEL C20001036M160S 8
R4271-4273 nsp 100-J,1/16W-1608REEL C20001016M160S 3
R4274-4276 nsp 10K-J,1/16W-1608REEL C20001036M160S 3
R4291 nsp 820-J,1/16W-1608REEL C20008216M160S 1
R4295 nsp 0-J,1/16W-1608REEL C20000006M160S 1
R4296 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4297 nsp 1K-J,1/16W-1608REEL C20001026M160S 1
R4300 nsp 10K-J,1/16W-1608REEL C20001036M160S 1
R4302 nsp 470K-J,1/16W-1608REEL C20004746M160S 1
R4305-4312 nsp 100K-J,1/16W-1608REEL C20001046M160S 8
R4551,4552 nsp 91K-J,1/16W-1608REEL C20009136M160S 2
R5300 nsp 47-J,1/16W-1608REEL E3, E2, E1C, JP C20004706M160S 1
R5304 nsp 47K-J,1/16W-1608REEL E3, E2, E1C, JP C20004736M160S 1
R5310 nsp 47K-J,1/16W-1608REEL E3, E2, E1C, JP C20004736M160S 1
R5311 nsp 47-J,1/16W-1608REEL E3, E2, E1C, JP C20004706M160S 1
R5312 nsp 4.7K-J,1/16W-1608REEL C20004726M160S 1
R5313,5314 nsp 33-J,1/16W-1608REEL C20003306M160S 2
R5340,5341 nsp 100-J,1/16W-1608REEL E3, E2, E1C, JP C20001016M160S 2
R5342 nsp 10K-J,1/16W-1608REEL E3, E2, E1C, JP C20001036M160S 1
R5343 nsp 12K-J,1/16W-1608REEL E3, E2, E1C, JP C20001236M160S 1
R5344 nsp 10K-J,1/16W-1608REEL E3, E2, E1C, JP C20001036M160S 1
R5345-5347 nsp 12K-J,1/16W-1608REEL E3, E2, E1C, JP C20001236M160S 3
CAPACIITORS GROUP
C2137 00D2570505910 CH)1500PF-J/50V-1608REEL GRM1882C1H152JA01D D010152167165S 1
C2139,2140 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 2
C2141 00D9630333203 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C2142 00D2570507976 CH)330PF-J/50V-1608REEL GRM1882C1H331JA01D D010331167165S 1
C2145 00D9630333203 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
6

Denon AVR-X2200W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Audyssey MultEQ XT	Yes
HDCP Support	2.2
AirPlay	Yes
Ethernet	Yes
Phono Input	Yes
Total Harmonic Distortion	0.08% (20Hz-20kHz)
HDMI Version	2.0a
4K Support	Yes
HDR Support	Yes
Dimensions (W x H x D)	434 x 167 x 339 mm
Power Output per Channel	95W (8 ohms, 20Hz - 20kHz, 0.08% THD)
USB Input	1
Frequency Response	10Hz - 100kHz
Inputs	8 HDMI, 2 component
Outputs	2 HDMI, 1 composite, 1 component
