Denon AVR-X4100W Owner's Manual

Upgrade (Auro-3D)
0
Auro-3D
This unit is equipped with an Auro-3D decoder.
With Auro-3D, Front Height (FHL+FHR) and Surround Height (SHL+SHR) are added to a conventional 5.1-channel system to achieve a natural and
realistic sound field that is three-dimensional and fully immersive.
After performing the Auro-3D upgrade you will be able to fully enjoy Auro-3D playback if you properly place the speakers for Auro-3D.
2Auro-3D Playback
.
FHL FHR
SHL
SHR
FL FR
SW
SL SR
C
2Dolby Atmos Playback
.
FHL FHR
SHL
SHR
FL FR
SW
SL SR
C
Auro-3D does not support a Dolby Atmos configuration using Top Front, Top Middle, Top Rear, Rear Height, or any Dolby Atmos Enabled speakers.
If you are using these speakers and want to take advantage of the Auro-3D Upgrade, you need to relocate them to Front Height and Surround Height speaker locations as
shown above.
It is possible to support both an Auro-3D and Dolby Atm
os by adding Front Height speakers to a 5.1-channel configuration.
Contents Connections Playback Settings Tips Appendix
12
Front panel Display Rear panel Remote Index

Denon AVR-X4100W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Pre-out connectivity	Yes
Audio output channels	- channels
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	8
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Speakers connectivity type	RCA
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
3D	-
Product color	Black
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	12600 g
