Advanced connections

7.1-channel playback

System for 7.1-channel surround playback.

You can connect speakers for up to 11-channels for MAIN ZONE. When you connect speakers for 8 or more channels, the output speakers

automatically switch according to the input signal and sound mode.

FHL

SBL

FHR

SBR

FWL

FWR

CENTER SURROUND

SURROUND BACK

SURROUNDFRONT

SURROUND BACK

FRONT

HEIGHT1 HEIGHT1

SBR SBL FWR FWL FHR FHLFR FL C SR SL

Contents Connections Playback Settings Tips Appendix
