Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” (v
p. 217) settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone
playback.
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed.
(v
p. 217)
Playback speaker in each zone
“Amp Assign” settings Connection page
MAIN ZONE ZONE2 ZONE3
5.1-channel playback Not used Not used 5.1ch + ZONE2 (Default)
46
7.1-channel playback Not used Not used 7.1ch 47
9.1-channel playback Not used Not used 9.1ch
48
5.1-channel playback (bi-amp connection of front speakers) Not used Not used 5.1ch (Bi-Amp) 49
7.1-channel playback + 2-channel speakers for stereo playback Not used Not used 7.1ch/2ch Front
50
5.1-channel playback + front speakers of second unit Not used Not used 5.1ch + Front B 51
5.1-channel playback 2-channel Not used 5.1ch + ZONE2 (Default)
52
5.1-channel playback Not used 2-channel 5.1ch + ZONE3 52
5.1-channel playback 1-channel 1-channel 5.1ch + ZONE2/3-MONO
53
Dolby Atmos playback Not used Not used Dolby Atmos 54
Contents Connections Playback Settings Tips Appendix
43
Front panel Display Rear panel Remote Index
