Connection 2 : TV equipped with an HDMI connector and incompatible with the ARC

(Audio Return Channel)

Use an HDMI cable to connect the TV to this unit.

To listen to audio from TV on this unit, use an optical cable to connect the TV to this unit.

CENTER SURROUND

SURROUND BACK

SURROUNDFRONT

SURROUND BACK

FRONT

HEIGHT1 HEIGHT1

OUT

OPTICAL

OUT IN

HDMI
