Denon AVR-X4100W

GWhen “Height Speakers” is set to “4 Height Speakers”H
Top Rear
z
:
The HEIGHT1 left and right pre-amp outputs
are connected to an external amplifier.
Surround Back &
Top Rear
z
:
The surround back/HEIGHT2 left and right pre-
amp outputs are connected to an external
amplifier.
Front Wide & Top
Rear
z
:
The front wide/HEIGHT2 left and right pre-amp
outputs are connected to an external amplifier.
Top Front & Top
Rear
z
:
The HEIGHT1/HEIGHT2 left and right pre-amp
outputs are connected to an external amplifier.
Front & Top Rear
z
:
The front left and right pre-amp outputs are
connected to an external amplifier.
z
The speaker name selected using “Height Layout” is displayed.
When one set of pre-amp outputs are used, a maximum 9.1-channel audio can
be output when Dolby Atmos or Dolby Surround are played back.
When two sets of pre-amp outputs are used, a maximum 9.1-channel audio can
be output when Audyssey DSX
®
or Neo:X are played back in addition to when
Dolby Atmos or Dolby Surround are played back.
