Denon AVR-X4100W

o
Layout including height speakers and top
speakers
n
Dolby Atmos layout example
Combination of 7.1-channel layout with surround back speaker and
top front/top rear speakers.
.
C
FL FR
SBL
SBR
SW
TRR
TRL
TFR
TFL
SL SR
n
DTS Neo:X layout example
Combination of 9.1-channel layout with surround back/front wide
speakers, and front height speakers.
.
FHL FHR
C
FL FR
SBL
SBR
SW
FWL
FWR
SL SR
