Denon AVR-X5200W User Manual

Upgrade
8
Accessories
9
Inserting the batteries
10
Operating range of the remote control unit
10
Features
11
High quality sound
11
High performance
13
Easy operation
16
Part names and functions
17
Front panel
17
Display
21
Rear panel
23
Remote control unit
26
Connections
Connecting speakers
30
Speaker installation
30
Speaker connection
40
Speaker configuration and “Amp Assign” settings
43
Connecting a TV
62
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel)
63
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel)
64
Connection 3 : TV equipped without an HDMI connector
65
Connecting a playback device
66
Connecting a set-top box (Satellite tuner/cable TV)
67
Connecting a DVD player or Blu-ray Disc player
68
Connecting a Blu-ray Disc player compatible with the Denon Link
HD function
69
Connecting a video camcorder or game console
70
Connecting a turntable
71
Connecting an iPod or USB memory device to the USB port
72
Connecting an HD Radio receiver
74
Connecting to a home network (LAN)
76
Wired LAN
76
Wireless LAN
77
Connecting an external control device
78
REMOTE CONTROL jacks
78
TRIGGER OUT jacks
79
Connecting the power cord
80
Contents Connections Playback Settings Tips Appendix
Contents
2
Front panel Display Rear panel Remote Index

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
