Denon AVR-X5200W User Manual

Speaker configuration and “Amp Assign” settings
This unit has a built-in 9-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” (v
p. 224) settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone
playback.
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed.
(v
p. 224)
Playback speaker in each zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2 ZONE3
5.1-channel playback Not used Not used 7.1ch + ZONE2 (Default)
46
7.1-channel playback (surround back) Not used Not used 7.1ch + ZONE2 (Default) 47
9.1-channel playback Not used Not used 9.1ch
48
11.1-channel playback Not used Not used 11.1ch 49
7.1-channel playback (bi-amp connection of front speakers) Not used Not used 7.1ch (Bi-Amp)
50
9.1-channel playback + 2-channel speakers for stereo playback Not used Not used 9.1ch/2ch Front 51
7.1-channel playback + 2-channel bi-amp speakers for stereo
playback
Not used Not used 7.1ch/2ch Front (Bi-Amp)
52
7.1-channel playback + front speakers of second unit Not used Not used 7.1ch + Front B 53
7.1-channel playback 2-channel Not used 7.1ch + ZONE2 (Default)
54
7.1-channel playback Not used 2-channel 7.1ch + ZONE3 54
5.1-channel playback (bi-amp connection of front speakers) 2-channel Not used 5.1ch (Bi-Amp) + ZONE2
55
5.1-channel playback 2-channel 2-channel 5.1ch + ZONE2/3 56
7.1-channel playback 1-channel 1-channel 7.1ch + ZONE2/3-MONO
57
Dolby Atmos playback Not used Not used Dolby Atmos 58
Upgrade (Auro-3D)
Playback speaker in each zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2 ZONE3
Auro-3D Not used Not used Auro-3D
60
Contents Connections Playback Settings Tips Appendix
43
Front panel Display Rear panel Remote Index

Denon AVR-X5200W Specifications

General

Receiver type	Surround
Frequency range	20 - 20000 Hz
Output impedance	16 Ω
Speaker selector	A+B
Pre-out connectivity	Yes
Audio output channels	- channels
Power output per channel (1KHz@6 Ohm)	205 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Remote (IR) input	1
Composite video in	5
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Connectivity technology	Wired & Wireless
Speakers connectivity type	-
Audio formats supported	AAC, AIFF, FLAC, MP3, WAV, WMA
Image formats supported	JPG
Supported radio bands	AM, FM
Internet radio services supported	Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby TrueHD, DTS 96/24, DTS Neo:X, DTS-ES, DTS-HD Master Audio
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	730 W

Weight and Dimensions

Depth	393 mm
Width	434 mm
Height	167 mm
Weight	14200 g
