Denon AVR-X5200W

GWhen “Height Speakers” is set to “4 Height Speakers” and “Wide/
Height2” is set to “Front Wide”H
Top Rear
z
:
The HEIGHT2 left and right pre-amp outputs are
connected to an external amplifier.
Top Front & Top
Rear
z
:
The HEIGHT1/HEIGHT2 left and right pre-amp
outputs are connected to an external amplifier.
Front & Top
Rear
z
:
The front/HEIGHT2 left and right pre-amp outputs
are connected to an external amplifier.
z
The speaker name selected using “Height Layout” is displayed.
When one set of pre-amp outputs are used, a maximum 11.1-channel audio can
be output when Dolby Atmos or Dolby Surround are played back. Furthermore,
when two sets of pre-amp outputs are used, a maximum 11.1-channel audio can
be output when Audyssey DSX
®
or Neo:X are played back in addition to when
Dolby Atmos or Dolby Surround are played back.
GWhen “Height Speakers” is set to “4 Height Speakers” and “Wide/
Height2” is set other than to “Front Wide”H
Front Wide:
The front wide left and right pre-amp outputs are
connected to an external amplifier.
Front & Front
Wide:
The front/front wide left and right pre-amp outputs are
connected to an external amplifier.
GWhen “Height Speakers” is set to “Using Dolby Speakers”H
Available settings differ depending on the “Height Layout” and “Wide/
Height2” settings.
Front:
The front left and right pre-amp outputs are
connected to an external amplifier.
Front Dolby
z
:
The HEIGHT1 left and right pre-amp outputs are
connected to an external amplifier.
Surround
Dolby
z
:
The HEIGHT2 left and right pre-amp outputs are
connected to an external amplifier.
Front Dolby &
Surr. Dolby
z
:
The HEIGHT1/HEIGHT2 left and right pre-amp
outputs are connected to an external amplifier.
Front & Surr.
Dolby
z
:
The front/HEIGHT2 left and right pre-amp outputs
are connected to an external amplifier.
Front Wide:
The front wide left and right pre-amp outputs are
connected to an external amplifier.
Front & Front
Wide:
The front/front wide left and right pre-amp outputs
are connected to an external amplifier.
z
The speaker name selected using “Height Layout” is displayed.
