Denon AVR-X5200W

n
Height Layout
Select the height channel used.
This can be selected when the “Speakers for ZONE3” setting is
“FRONT WIDE/HEIGHT2” or “SURROUND BACK”.
AUDIO OUT connectors
Select items
HEIGHT1
None No height channels are used.
Front Height
(Default)
Front Height
Top Front Top Front
Top Middle Top Middle
Top Rear Top Rear
Rear Height Rear Height
Front Dolby Front Dolby
Surround Dolby Surround Dolby
o
Detailed settings when “Assign Mode” is set to
“7.1ch + ZONE2/3-MONO”
When “Assign Mode” is set to “7.1ch + ZONE2/3-MONO”, set the
following items.
n
Speakers for ZONE2/3
Select speaker terminals that output audio in ZONE2 and ZONE3.
The channels of speaker terminals selected for ZONE2/ZONE3 cannot
be output in MAIN ZONE.
FRONT WIDE/
HEIGHT2
(Default):
Outputs audio in ZONE2 from the L channel of
FRONT WIDE/HEIGHT2 speaker terminals and
audio in ZONE3 from the R channel.
HEIGHT1:
Outputs audio in ZONE2 from the L channel of
HEIGHT1 speaker terminals and audio in ZONE3
from the R channel.
SURROUND
BACK:
Outputs audio in ZONE2 from the L channel of
SURROUND BACK speaker terminals and audio in
ZONE3 from the R channel.
