Denon DCD-1520AE - Rear Panel

11
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Display Rear panel IndexRemote
Rear panel
wert
q
q AUDIO OUT connectors
Used to connect devices equipped with analog audio inputs connectors
or an external power amplifier (vpage18).
w AC inlet (AC IN)
Used to connect the power cord (vpage25).
e REMOTE CONTROL IN/OUT connectors
Extension jack for future use.
r DIGITAL AUDIO IN connectors
Used to connect devices equipped with digital audio output connectors
(vpage20, 21).
t DIGITAL AUDIO OUT connectors
Used to connect an AV receiver or D/A converter equipped with digital
audio input connectors (vpage19).
