30
DHT-FS5
TAS5186A Terminal Function
TERMINAL FUNCTIONS
TERMINAL
TYPE
(1)
DESCRIPTION
NAME NO.
AGND 12 P Analog ground
BST_A 23 P HS bootstrap supply (BST), capacitor to OUT_A required
BST_B 29 P HS bootstrap supply (BST), external capacitor to OUT_B required
BST_BIAS 21 P BIAS bootstrap supply, external capacitor to OUT_BIAS required
BST_C 30 P HS bootstrap supply (BST), external capacitor to OUT_C required
BST_D 37 P HS bootstrap supply (BST), external capacitor to OUT_D required
BST_E 38 P HS bootstrap supply (BST), external capacitor to OUT_E required
BST_F 44 P HS bootstrap supply (BST), external capacitor to OUT_F required
GND 11 P Chip ground
GVDD_ABC 20 P Gate drive voltage supply
GVDD_DEF 3 P Gate drive voltage supply
M1 10 I Mode selection pin
M2 9 I Mode selection pin
M3 8 I Mode selection pin
OC_ADJ 14 O Overcurrent threshold programming pin, resistor to ground required
OTW
16 O Overtemperature warning open-drain output signal, active-low
OUT_A 25 O Output, half-bridge A, satellite
OUT_B 27 O Output, half-bridge B, satellite
OUT_BIAS 22 O BIAS half-bridge output pin
OUT_C 32 O Output, half-bridge C, subwoofer
OUT_D 35 O Output, half-bridge D, satellite
OUT_E 40 O Output, half-bridge E, satellite
OUT_F 42 O Output, half-bridge F, satellite
1,
26,
PGND 33, P Power ground
34,
41
PVDD_A 24 P Power-supply input for half-bridge A
PVDD_B 28 P Power-supply input for half-bridge B
PVDD_C 31 P Power-supply input for half-bridge C
PVDD_D 36 P Power-supply input for half-bridge D
PVDD_E 39 P Power-supply input for half-bridge E
PVDD_F 43 P Power-supply input for half-bridge F
PWM_A 19 I PWM input signal for half-bridge A
PWM_B 18 I PWM input signal for half-bridge B
PWM_C 17 I PWM input signal for half-bridge C
PWM_D 6 I PWM input signal for half-bridge D
PWM_E 5 I PWM input signal for half-bridge E
PWM_F 2 I PWM input signal for half-bridge F
RESET
7 I Reset signal (active-low logic)
SD 15 O Shutdown open-drain output signal, active-low
VDD 4 P Power supply for digital voltage regulator
VREG 13 O Digital regulator supply filter pin, output
(1) I = input; O = output; P = power
