Denon DHT-FS5 Service Manual

40
DHT-FS5
PARTS LIST OF P.W.B. UNIT
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan mode
SKA SIGNAL P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
7200 nsp IC SM NJM2750M
932219831668
7201 nsp IC SM UDA1361TS/N1 935267099118
7202 nsp IC SM AK4113VF 932223308669
7203 nsp IC SM 74LVC125A 319801070520
7205 nsp IC SM TS972IP 932219493668
7301 nsp IC SM 74HC1GU04GW 319801071190
7302 nsp IC SM 74HC1GU04GW 319801071190
7304 nsp IC SM 74LVC1G125GW 319801071250
7307 nsp IC SM NCP301LSN42G 310413051030
7308 nsp Venice microcontroller assy 310413710061
7310 nsp IC SM 74LVC2G241DP 935272006118
7311 nsp IC SM LD1117DT 932214497668
7312 nsp IC SM LF33CD 932212167668
7313 nsp IC SM LF33CPT 932213916668
7314 nsp IC SM 74HC1GU04GW 319801071190
7315 nsp EEP ROM ASSY IC SM M24C02-WMN6P 932220624668
7400 nsp IC SM DSPC56371AF180 932224158671
7401 nsp Venice DSP-flash assy IC M25P20-VMN 310413710071
7204 nsp TRA SIG SM BC847B 319801042030
7206 nsp TRA SIG SM BC847B 319801042030
7207 nsp TRA POW SM PBSS5120T 934057987215
7208 nsp TRA SIG SM BC847B 319801042030
7209 nsp TRA SIG SM BC847B 319801042030
7210 nsp TRA SIG SM BC857B 319801042150
7211 nsp TRA SIG SM BC847B 319801042030
7212 nsp TRA SIG SM BC847B 319801042030
7309 nsp TRA SIG SM BC847B 319801042030
6202 nsp DIO SIG SM BAS316 319801010630
6203 nsp DIO SIG SM BAS316 319801010630
6204 nsp DIO SIG SM BAS316 319801010630
6205 nsp DIO SIG SM BAS316 319801010630
6206 nsp DIO SIG SM BAT54S 933976380215
6208 nsp DIO SIG SM BAS316 319801010630
6209 nsp DIO SIG SM BAS316 319801010630
6303 nsp DIO SIG SM BAT54S 933976380215
6304 nsp DIO SIG SM BAT54S 933976380215
6400 nsp DIO SIG SM BAT54 SOD323 319801010660
RESISTORS GROUP
3200 nsp RST SM 0603 10R PM5
319802131090
3202 nsp RST SM 0603 220R PM5 319802132210
3203 nsp RST SM 0603 47K PM5 319802134730
3204 nsp RST SM 0603 10K PM5 319802131030
3205 nsp RST SM 0603 10K PM5 319802131030

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
