Denon DHT-FS5 Service Manual

60
DHT-FS5
EXPLODED VIEW
u
W8
W6
W7
y
W5
total cabinet assy
Q1
W2
W1
W3
W4
Q9
Q8
Q7
e
r
w
t
Q6
W0
z
Q4
Q3
Q2
Q5
q
Q0
frame -LED assy(JP,EX)
button on/standby assy
o
i
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:
印の部分は安全を維持するために重要
な部品です。従って交換時は必ず指定の
部品を使用してください。

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
