61
DHT-FS5
PARTS LIST OF EXPLODED VIEW
*本表に"nsp" と記載されている部品は供給できません。
Parts for which "nsp" is indicated on this table cannot be supplied.
本表に"nsp" と記載されている基板 ASS’Y は供給できません。基板 ASS’Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。
P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.
*本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
Ref.
No.
Part No. Part Name Remarks Q'ty New
1 00D9710014902 Venice Front pb Assy E3,E2
310413700493
1 *
1 00D9710014805 Venice Front pb Assy JP
310413700453
1 *
2 00D9710014300 Venice Connector pb Assy
310413700433
1 *
3 00D9710014407 Venice amplifier pb Assy
310413700467
1 *
4 00D9710014504 Venice signal pb assy JP
310413700476
1 *
4 00DSPK582E2 Venice signal pb assy E2
-
1 *
4 00DSPK582E3 Venice signal pb assy E3
-
1 *
5 00D9710014708 SKA PSU 120V Board Assy E3,JP
310421708322
1 *
5 00D9710014601 SKA PSU 230V Board Assy E2
310421708312
1 *
6 nsp total cover-bottom assy Black model
434107892801
1 *
6 nsp total cover-bottom assy Silver model
434107892911
1 *
7 00D9710015804 cloth-frame assy black Black model
434107892811
1 *
7 00D9710015901 cloth-frame assy silver Silver model
434107892941
1 *
8 00D9710017908 frame-LED assy(JP) JP
244125730182
1 *
8 00D9710018002 frame-LED assy(EX) E3,E2
244125730183
1 *
- plate-ornamental-EX-B E3,E2
434107453951
1
- plate-ornamental black JP
434107453752
1
- plate-color green E3,E2
434107453891
1
- plate-color red JP
434107453771
1
- frame-LED island black
434107453701
1
- plate-diffusor
434107453761
1
9 00D9710017805 button-on/standby assy
244125730181
1 *
- button-on/standby black
434107453661
1
- lens
434107453712
1
10 nsp reflector-LED
434107453652
1 *
11 nsp total cover-rear assy E3
434107893061
1 *
11 nsp total cover-rear assy E2
434107893101
1 *
11 nsp total cover-rear assy JP
434107892821
1 *
12 nsp plate-shielding
434107135922
1 *
13 nsp bracket A
434107135941
1 *
14 nsp bracket B
434107135951
1 *
15 nsp shielding-O-P
434107135931
1 *
16 nsp cover-rear-ex E3,E2
434107453991
1 *
16 nsp cover-rear JP
434107453642
1 *
17 nsp plate-Al
434107135972
1 *
18 nsp Foam cushion
310421310331
2
19 00D9710001806 FAN 12VDC 0.6W 5200RPM B
282203100019
1
z 20 00D9710016201 mains cord(USA) E3
314113760801
1 *
z 20 00D9710016104 mains cord(EU) E2
314113760791
1 *
z 20 00D9710016007 mains cord(japan) JP
314113760722
1 *
21 nsp total cabinet assy-ex-B E3,E2 Black model
434107893131
1 *
21 nsp total cabinet assy-ex-S E2 Silver model
434107893091
1 *
21 nsp total cabinet assy JP Black model
434107892881
1 *
21 nsp total cabinet assy JP Silver model
434107892951
1 *
22 nsp cabinet assy-ex-B E3,E2 Black model
434107893141
1 *
22 nsp cabinet assy-ex-S E2 Silver model
434107893151
1 *
