Denon DHT-FS5 Service Manual

62
DHT-FS5
22 nsp cabinet assy black JP Black model 434107892841 1 *
22 nsp cabinet assy silver JP Silver model
434107892961 1 *
23 00D9710016609 Venice 3 inches ferrite 25W/6 Ohm
434107863221 4 *
24 00D9710016706 Venice 3 inches Nd 25W/6 Ohm
434107863231 2 *
25 nsp Grommet (round)
434070450391 2
26 nsp Grommet (oval)
310421310391 8
27 nsp foam A
434107307702 2 *
28 nsp foam B
434107307711 2 *
★ 29
nsp Foam
434107306211 4 *
★ 30
nsp Serial number label
310421536441 1 *
★ 31
nsp label-rating-USA E3
434107551311 1 *
★ 31
nsp label-rating-EU E2
434107551291 1 *
★ 31
nsp label-rating JP
434107551222 1 *
★ 51
00D9710006102 Flex cable 18Pin P=1.0mm L=80mm typeD
310421816241 1
★ 52
00D9710006209 Flex cable 16Pin P=1.0mm L=80mm typeD (1-1)
310421816251 1
★ 53
00D9710006306 Flex cable 15Pin P=1.0mm L=80mm typeD (1-1)
310421816261 1
★ 54
nsp PH-PH 5F AWG26 500mm 1-1
310421816211 1
★ 55
nsp cable VH-3 L215
314113760712 1
★ 56
nsp cable PH-9 L210
314113760731 1
★ 57
nsp cable XAP-12V-1/fastons L470
314113760742 1
★ 58
nsp cable XARR-12 L135
314113760751 1
★ 59
nsp cable EH-2 L100
314113760771 1
SCREWS
★ 101
nsp Screw St Zn 3x10
434070420191 16
★ 101
nsp Screw St Zn 3x10
434070420191 5
★ 101
nsp Screw St Zn 3x10
434070420191 38
★ 102
nsp Screw St Zn 3x10 washer
434107045681 3
★ 102
nsp Screw St Zn 3x10 washer
434107045681 19
★ 102
nsp Screw St Zn 3x10 washer
434107045681 2
★ 103
nsp Tapt. screw St Zn 3x8
434107045131 3
★ 104
nsp Screw St Zn 3x12-spring-flat
434107045842 16
Ref.
No.
Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
