Denon DHT-FS5 Service Manual

63
DHT-FS5
DHT-FS5 PACKING VIEW
DHT-FS5 PARTS LIST OF PACKING & ACCESSORIES
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
201 00D9710013205 box-individual 434107633041 1
202 00D9710015105 Remote control-EX E3,E2
314113800221 1*
202 00D9710015008 Remote control JP
314113800211 1*
203 00D9710000205 Stereo audio cable
310421816341 1
204 00D9710000302 Optical cable
310421816351 1
205 nsp Battery set (2x AAA)
310421753811 1
206 00D9710015309 INST.MANUAL (EX) E3,E2
434107611431 1*
206 00D9710015202 INST.MANUAL (Japanese) JP
434107611341 1*
207 00D9710016405 Quick start guide E3,E2
434107611441 1*
207 00D9710016308 Quick start guide JP
434107611351 1*
208 nsp Service network List(EU+UL) E3,E2
434107551102 1
208 nsp Service Station List JP
310421536431 1
209 nsp Limited Warranty card(UL) E3
434107551121 1
210 nsp Japanese guarantee card JP
434107611361 1
211 nsp polybag
434107632601 2
212 00D9710000700 CBS-screw assy
310421753901 1
213 00D9710000506 Total Foot 35mm assy packed JP
310421753731 1
213 00D9710000409 Total Foot 25mm assy packed E3,E2
310421753721 1
218
216
217
215
201 214
〜

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
