Denon DHT-FS5 Service Manual

34
DHT-FS5
2. LED
DA56-11GWA (7108)
No.
1
9
2
3
4
5
6
7
8
10
11
12
13
14
15
16
17
18
CONNECTION
CATHODE E , DIG1
CATHODE D , DIG1
CATHODE C , DIG1
COMMON ANODE , DIG1
CATHODE B , DIG1
CATHODE DP1 , DIG1
CATHODE E , DIG2
CATHODE G , DIG2
CATHODE DP2 , DIG2
CATHODE B , DIG2
CATHODE A , DIG2
CATHODE F , DIG2
COMMON ANODE , DIG2
CATHODE A , DIG1
CATHODE G , DIG1
CATHODE F , DIG1
, DIG2CATHODE D
, DIG2CATHODE C

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
