Denon DHT-FS5 Service Manual

42
DHT-FS5
3313 nsp RST SM 0603 100R PM5 319802131010
3314 nsp RST SM 0603 100R PM5 319802131010
3315 nsp RST SM 0603 10K PM5 319802131030
3316 nsp RST SM 0603 100R PM5 319802131010
3317 nsp RST SM 0603 100R PM5 319802131010
3318 nsp RST SM 0603 100R PM5 319802131010
3319 nsp RST SM 0603 100R PM5 319802131010
3320 nsp RST SM 0603 100R PM5 319802131010
3321 nsp RST SM 0603 2K7 PM5 319802132720
3322 nsp RST SM 0603 2K7 PM5 319802132720
3323 nsp RST SM 0603 10K PM5 319802131030
3324 nsp RST SM 0603 1K0 PM5 319802131020
3325 nsp RST SM 0603 1K0 PM5 319802131020
3326 nsp RST SM 0603 10K PM5 319802131030
3327 nsp RST SM 0603 10K PM5 319802131030
3328 nsp RST SM 0603 10K PM5 319802131030
3330 nsp RST SM 0603 100R PM5 319802131010
3331 nsp RST SM 0603 10K PM5 319802131030
3332 nsp RST SM 0603 100R PM5 319802131010
3333 nsp RST SM 0603 10K PM5 319802131030
3334 nsp RST SM 0603 10K PM5 319802131030
3335 nsp RST SM 0603 100R PM5 319802131010
3336 nsp RST SM 0603 100R PM5 319802131010
3337 nsp RST SM 0603 100R PM5 319802131010
3338 nsp RST SM 0603 100R PM5 319802131010
3339 nsp RST SM 0603 4K7 PM5 319802134720
3340 nsp RST SM 0603 100R PM5 319802131010
3341 nsp RST SM 0603 100R PM5 319802131010
3342 nsp RST SM 0603 100R PM5 319802131010
3343 nsp RST SM 0603 6K8 PM5 319802136820
3344 nsp RST SM 0603 3K3 PM5 319802133320
3345 nsp RST SM 0603 JUMP. 0R05 319802190030
3346 nsp RST SM 0603 10R PM5 319802131090
3347 nsp RST SM 0603 10R PM5 319802131090
3348 nsp RST SM 0603 10R PM5 319802131090
3349 nsp RST SM 0603 120R PM5 319802131210
3350 nsp RST SM 0603 10K PM5 319802131030
3351 nsp RST SM 0603 1K0 PM5 319802131020
3352 nsp RST SM 0603 10K PM5 319802131030
3353 nsp RST SM 0603 10K PM5 319802131030
3354 nsp RST SM 0603 10R PM5 319802131090
3355 nsp RST SM 0603 47R PM5 319802134790
3356 nsp RST SM 0603 100R PM5 319802131010
3357 nsp RST SM 0603 4K7 PM5 319802134720
3358 nsp RST SM 0603 22K PM5 319802132230
3359 nsp RST SM 0603 100R PM5 319802131010
3360 nsp RST SM 0603 470R PM5 319802134710
3363 nsp RST SM 0603 22K PM5 319802132230
3365 nsp RST SM 0603 4K7 PM5 319802134720
3366 nsp RST SM 0603 100R PM5 319802131010
3367 nsp RST SM 0603 100R PM5 319802131010
3368 nsp RST SM 0603 22K PM5 319802132230
3406 nsp RST SM 0603 10K PM5 319802131030
3407 nsp RST SM 0603 10K PM5 319802131030
3408 nsp RST SM 0603 10K PM5 319802131030
3409 nsp RST SM 0603 10K PM5 319802131030
Ref. No. Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
