Denon DHT-FS5 Service Manual

44
DHT-FS5
2238 nsp CER1 0603 NP0 50V 47P 319801634790
2239 nsp CER1 0603 NP0 50V 47P 319801634790
2240 nsp CER1 0603 NP0 50V 47P 319801634790
2241 nsp CER1 0603 NP0 50V 47P 319801634790
2242 nsp CER1 0603 NP0 50V 47P 319801634790
2243 nsp CER1 0603 NP0 50V 47P 319801634790
2244 nsp CER2 0603 X7R 16V 100N 319801731040
2245 nsp CER1 0603 NP0 50V 47P 319801634790
2246 nsp CER1 0603 NP0 50V 47P 319801634790
2247 nsp CER1 0603 NP0 50V 47P 319801634790
2248 nsp CER1 0603 NP0 50V 47P 319801634790
2249 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2250 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2251 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2252 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2253 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2254 nsp ELCAP SM 16V 47U PM20 319803044790
2255 nsp CER2 0603 X7R 16V 470N PM10 202055200189
2256 nsp CER1 0603 NP0 50V 47P 319801634790
2257 nsp CER1 0603 NP0 50V 47P 319801634790
2258 nsp CER1 0603 NP0 50V 47P 319801634790
2259 nsp ELCAP SM 35V 10U PM20 319803071090
2260 nsp CER1 0603 NP0 25V 1N0 319801631020
2261 nsp CER1 0603 NP0 50V 100P 319801631010
2300 nsp CER2 0603 X7R 16V 100N 319801731040
2301 nsp CER2 0603 X7R 16V 100N 319801731040
2302 nsp ELCAP SM 16V 47U PM20 319803044790
2303 nsp CER1 0603 NP0 50V 33P PM5 223886715339
2304 nsp CER1 0603 NP0 50V 33P PM5 223886715339
2305 nsp CER2 0603 X7R 16V 100N 319801731040
2306 nsp CER2 0603 X7R 16V 100N 319801731040
2307 nsp CER2 0603 X7R 16V 100N 319801731040
2308 nsp CER2 0603 X7R 16V 100N 319801731040
2309 nsp CER1 0603 NP0 50V 100P 319801631010
2310 nsp CER1 0603 NP0 50V 100P 319801631010
2311 nsp CER1 0603 NP0 50V 100P 319801631010
2312 nsp CER1 0603 NP0 50V 100P 319801631010
2313 nsp CER1 0603 NP0 50V 100P 319801631010
2315 nsp CER2 0603 X7R 16V 100N 319801731040
2316 nsp CER1 0603 NP0 50V 100P 319801631010
2317 nsp CER1 0603 NP0 50V 100P 319801631010
2318 nsp CER2 0603 X7R 16V 100N 319801731040
2319 nsp CER2 0603 X7R 16V 100N 319801731040
2320 nsp CER1 0603 NP0 50V 100P 319801631010
2321 nsp CER2 0603 X7R 16V 100N 319801731040
2322 nsp ELCAP SM 35V 10U PM20 319803071090
2323 nsp CER2 0603 X7R 16V 100N 319801731040
2324 nsp ELCAP SM 35V 10U PM20 319803071090
2325 nsp ELCAP SM 16V 47U PM20 319803044790
2326 nsp CER2 0603 X7R 16V 100N 319801731040
2327 nsp CER2 0603 X7R 16V 100N 319801731040
2328 nsp ELCAP SM 35V 10U PM20 319803071090
2329 nsp CER2 0603 X7R 16V 100N 319801731040
2330 nsp CER2 0603 X7R 16V 100N 319801731040
2331 nsp CER2 0603 X7R 16V 100N 319801731040
2332 nsp CER2 0603 X7R 16V 100N 319801731040
Ref. No. Part No. Part Name Remarks Q'ty New

Denon DHT-FS5 Specifications

General

Type	Home theatre speakers
Frequency range	80 - 20000 Hz
Dimensions (WxDxH)	750 x 138 x 118 mm
Satellite speaker driver diameter	3.15 \
Audio output channels	5.0 channels
Impedance	6 Ω
RMS rated power	150 W
Signal-to-Noise Ratio (SNR)	100 dB
Microphone in	Yes
Product color	Black

Weight and Dimensions

Weight	5100 g
