Signal system chart
USB settings
Items
(Lit display (LED))
MIDI command
Command Number Value
37 PLAY
CC : 0xBn
ON TRG : 74
OFF TRG : 75
Blink ON TRG : 76
39
38 LOOP IN 36
39 LOOP IN Dimmer 62
40 LOOP OUT 64
41 LOOP OUT Dimmer 42
42 AUTO LOOP 43
43 AUTO LOOP Dimmer 83
44 EFX.1 Dimmer (FX1) 44
45 EFX.2 Dimmer (FX1) 45
46 EFX.3 Dimmer (FX1) 46
47 EFX.4 Dimmer (FX1) 47
48 EFX.1 Dimmer (FX2) 58
49 EFX.2 Dimmer (FX2) 59
50 EFX.3 Dimmer (FX2) 60
51 EFX.4 Dimmer (FX2) 61
52 FX ON 1 90
53 FX ON 2 91
54 EFX 1 (FX1) 92
55 EFX 2 (FX1) 93
56 EFX 3 (FX1) 94
57 EFX 4 (FX1) 95
58 EFX 1 (FX2) 96
59 EFX 2 (FX2) 97
60 EFX 3 (FX2) 98
61 EFX 4 (FX2) 99
62 ALLSLIDER/VOLUME/FADERREQUEST 74 57
63 CUE (DECK A)
ON TRG : 80
OFF TRG : 81
69
64 CUE Dimmer (DECK A) 70
65 CUE (DECK C) 75
66 CUE Dimmer (DECK C) 76
67 CUE (DECK B) 81
68 CUE Dimmer (DECK B) 82
Items
(Lit display (LED))
MIDI command
Command Number Value
69 CUE (DECK D)
CC : 0xBn
ON TRG : 80
OFF TRG : 81
87
70 CUE Dimmer (DECK D) 88
71 DUCKING 99
72 CF MODE (AUDIO) 97
73 CFMODE(VIDEO) 98
74 METER 4 (DECK A) 10
75 METER 5 (DECK A) 11
76 METER 6 (DECK A) 12
77 METER 7 (DECK A) 13
78 METER 8 (DECK A) 14
79 METER 9 (DECK A) 15
80 METER PEAK (DECK A) 16
81 METER 4 (DECK C) 26
82 METER 5 (DECK C) 27
83 METER 6 (DECK C) 28
84 METER 7 (DECK C) 29
85 METER 8 (DECK C) 30
86 METER 9 (DECK C) 31
87 METER PEAK (DECK C) 32
88 METER 4 (DECK B) 42
89 METER 5 (DECK B) 43
90 METER 6 (DECK B) 44
91 METER 7 (DECK B) 45
92 METER 8 (DECK B) 46
93 METER 9 (DECK B) 47
94 METER PEAK (DECK B) 48
95 METER 4 (DECK D) 58
96 METER 5 (DECK D) 59
97 METER 6 (DECK D) 60
98 METER 7 (DECK D) 61
99 METER 8 (DECK D) 62
100 METER 9 (DECK D) 63
101 METER PEAK (DECK D) 64
z n=MIDI CH = 0 – 15
