Signal system chart
Part names and
functions
Front panel
For buttons not explained here, see the page indicated in parentheses ( ).
q
q Headphone jack (PHONES) ························ (10)
Rear panel
For buttons not explained here, see the page indicated in parentheses ( ).
trewq oiuy
q Theft protection lock hole
Connect to an anti-theft wire.
w AC adapter cord holder ································ (4)
This prevents the AC adapter plug from
disconnecting.
Use a Phillips screwdriver to anchor the AC
adapter cable to this holder.
e DC IN jack (DC IN) ········································· (4)
r Power switch (POWER) ····························· (10)
NOTE
There is no function on this device for
automatically switching off the power supply
when the unit is not used for a prolonged
period.
If you do not intend to use this device for a
prolonged period, for safety either switch off the
power supply, or remove the AC adaptor plug
from the wall socket.
t USB terminal (USB) ····································· (4)
y Master output terminal
(MASTER OUT BALANCED) ························ (3)
u Master output terminal
(MASTER OUT UNBALANCED) ··················· (3)
i Line 1/2 input terminal
(LINE 1/2) ······················································ (3)
o Balanced microphone input terminal
(MIC) ······························································ (3)
To Next Page
