Denon RCD-N8 Service Manual

MAIN
Ref. No. Part No. Part Name Remarks Q'ty New Ver
C116 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C117 nsp C,CERAMIC CHIP HIK X7R4700PF-K/50V-1608REEL D011472777160S 1
C118 nsp C,CERAMIC CHIP T.C X7R 0.068UF-K/50V-1608REEL D010683777160S 1
C119 00D2544694909 C,ELECT GE 85C 100UF-M/25V,6.3*11 RFO-25V101M ELNA D040101084330S 1
C120,121 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C122,123 00D9630338606 C,ELECT CHIP(GE) 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 1
C124,125 963134502210S C,ELECT CHIP(GE) 22UF-MV/6.3V,3.3*3.7*5.2 REEL (Z8154) SY D050220081460S 1
C126,127 nsp C,CERAMIC CHIP T.C COG)10PF-J/50V-1608REEL D010100167161S 1
C128,129 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C130 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C131-133 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C134 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C135 00D9630333203 C,ELECT GE 85C 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C136-140 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C141 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C142 00D9639006557 C,ELECT GE 85C 220UF-M/6.3V,5*11-5RE-SHL SY D040221081060S 1
C143-145 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C146 nsp C,CERAMIC CHIP T.C COG12PF-J/50V-1608REEL D010120167160S 1
C147 nsp C,CERAMIC CHIP T.C COG15PF-J/50V-1608REEL D010150167160S 1
C148-150 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C151 00D9639006557 C,ELECT GE 85C 220UF-M/6.3V,5*11-5RE-SHL SY D040221081060S 1
C152 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C153 963134001860S C,ELECT GE 85C 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C154-157 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C158,159 963134001860S C,ELECT GE 85C 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C160 963134502140S C,ELECT GE 85C 3300UF-M/50V 18*35.5L BLK SY D040332087000S 1
C161 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C162 nsp C,CERAMIC CHIP HIK Y5V)0.033UF-K/100V-2012REEL D01133357C201S 1
C163,164 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C165,166 nsp C,CERAMIC CHIP HIK Y5V)0.033UF-K/100V-2012REEL D01133357C201S 1
C167,168 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C169 nsp C,CERAMIC CHIP HIK Y5V)0.033UF-K/100V-2012REEL D01133357C201S 1
C170 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C171 963134502140S C,ELECT GE 85C 3300UF-M/50V 18*35.5L BLK SY D040332087000S 1
C172-175 nsp C,CERAMIC CHIP HIK X7R330PF-K/50V-2012REEL D011331177210S 1
C176 nsp C,FILM POLYESTER RED-0.47UF-J/100V-5RE MPEAM474J10005 MPE TYPE(S&A) D02047406C050S 1
C177,178 nsp C,FILM POLYESTER ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 1
C179 nsp C,FILM POLYESTER RED-0.47UF-J/100V-5RE MPEAM474J10005 MPE TYPE(S&A) D02047406C050S 1
C180,181 nsp C,FILM POLYESTER ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 1
C182-185 nsp C,FILM POLYESTER ST-0.01UF-J/100V-5RE PEFAM103J100 PEF TYPE D02010306C060S 1
C186-189 nsp C,FILM POLYESTER ST-0.1UF-J/100V-5RE PEFAM104J100 PEF TYPE D02010406C060S 1
C190,191 963134501660S C,ELECT GE 85C 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C192 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C193 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C194,195 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C196 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C197,198 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C199 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C200 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C201,202 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C203,204 00D2544541939 C,ELECT GE 85C 47UF-M/25V 5*11-5RE.SMS SY D040470084070S 1
C205,206 nsp C,CERAMIC CHIP T.C COG270PF-J/50V-1608REEL D010271167160S 1
C207,208 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C209 00D2544573981 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C210 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C211,212 nsp C,CERAMIC CHIP T.C COG270PF-J/50V-1608REEL D010271167160S 1
C213,214 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C215 00D2544573981 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C216 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C217,218 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C219,220 00D2544541939 C,ELECT GE 85C 47UF-M/25V 5*11-5RE.SMS SY D040470084070S 1
C221,222 00D9630293602 C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C223 nsp C,CERAMIC CHIP HIK X7R4700PF-K/50V-1608REEL D011472777160S 1
C224,225 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C226 00D2544740921 C,ELECT CHIP(GE) 47UF-MVG/16V,5.3*5.9*5.3 REEL (Z8156) SY D050470083200S 1
C227,228 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C229 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C230 00D2544694909 C,ELECT GE 85C 100UF-M/25V,6.3*11 RFO-25V101M ELNA D040101084330S 1
C231 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C232 00D2544694909 C,ELECT GE 85C 100UF-M/25V,6.3*11 RFO-25V101M ELNA D040101084330S 1
C233 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C234-236 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C237,238 963134501660S C,ELECT GE 85C 220UF-M/25V,8*11.5-5RE.SMS SY D040221084060S 1
C239 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-2012REEL D011102777200S 1
C240 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-2012REEL D011104777200S 1
C241 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-2012REEL D011103777200S 1
C242-244 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C245 nsp C,CERAMIC CHIP T.C COG)10PF-J/50V-1608REEL D010100167161S 1
C246 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C247-250 963134502190S C,ELECT CHIP(GE) 47UF-M/50V,8.3*9.0*10 REEL MVG (Z8158) SY D050470087250S 1
C251 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C252 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C253 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C262-264 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C265 00D2544574922 C,ELECT GE 85C 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C266 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C267 00D2544574922 C,ELECT GE 85C 100UF-M/50V,8*11.5-5RE.SMS SY D040101087060S 1
C268 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C269 nsp C,CERAMIC CHIP HIK Y5V0.01UF-Z/50V-1608REEL D011103597160S 1
C270,271 00D2544302974 C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C272 nsp C,CERAMIC CHIP HIK Y5V0.01UF-Z/50V-1608REEL D011103597160S 1
C273 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C274,275 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C276 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C277,278 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C279-282 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C283 00D2544738917 C,ELECT CHIP(GE) 220UF-M/16V 6.3*7.7 REEL (Z8157) SY D050221083200S 1
C284 nsp C,CERAMIC CHIP HIK Y5V0.01UF-Z/50V-1608REEL D011103597160S 1
C285 00D2544738917 C,ELECT CHIP(GE) 220UF-M/16V 6.3*7.7 REEL (Z8157) SY D050221083200S 1
C286 nsp C,CERAMIC CHIP HIK Y5V0.01UF-Z/50V-1608REEL D011103597160S 1
C287-290 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C291 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C301 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C302 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C303 nsp C,CERAMIC CHIP HIK X7R)1UF-K/10V-1608REEL D011105772161S 1
C304 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C305 nsp C,CERAMIC CHIP HIK X7R)1UF-K/10V-1608REEL D011105772161S 1
C306 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C307 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C308 nsp C,CERAMIC CHIP HIK X7R)1UF-K/10V-1608REEL D011105772161S 1
C309 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
5

Denon RCD-N8 Specifications

General

Remotely operated	Yes
Security algorithms	WPS
Supported radio bands	FM, VHF
Built-in storage media	No
Audio formats supported	MP3
Internet radio services supported	iDevice, iTunes
Network streaming services supported	-
Product color	White
RMS rated power	130 W
Wi-Fi standards	802.11b, 802.11g
Digital audio optical out	1
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	50 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4000 g
