Denon RCD-N8 Service Manual

MAIN
Ref. No. Part No. Part Name Remarks Q'ty New Ver
C310 nsp C,CERAMIC CHIP HIK X7R)1UF-K/10V-1608REEL D011105772161S 1
C311 nsp C,CERAMIC CHIP HIK X5R)10UF-M/6.3V-1608REEL JMK107BJ106KA-T D011106581160S 1
C312 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C313 nsp C,CERAMIC CHIP HIK X5R)10UF-M/6.3V-1608REEL JMK107BJ106KA-T D011106581160S 1
C314 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C318 nsp C,CERAMIC CHIP HIK X7R5600PF-K/50V-1608REEL D011562777160S 1
C319 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C320-323 nsp C,CERAMIC CHIP HIK X5R)10UF-M/6.3V-1608REEL JMK107BJ106KA-T D011106581160S 1
C324 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C326 nsp C,CERAMIC CHIP HIK X7R4700PF-K/50V-1608REEL D011472777160S 1
C327 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C328-331 nsp C,CERAMIC CHIP HIK X5R)10UF-M/6.3V-1608REEL JMK107BJ106KA-T D011106581160S 1
C332 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C334 nsp C,CERAMIC CHIP HIK X7R3300PF-K/50V-1608REEL D011332777160S 1
C335 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C336-339 nsp C,CERAMIC CHIP HIK X5R)10UF-M/6.3V-1608REEL JMK107BJ106KA-T D011106581160S 1
C340 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C342 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C343 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C345 00D9630333203 C,ELECT GE 85C 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C347 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C349 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C350 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C351 00D9630333203 C,ELECT GE 85C 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C352 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C353 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C354 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C355 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C357 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C358,359 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C361 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C362 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C363 00D2544538913 C,ELECT GE 85C 22UF-M/16V,5*11-5RE.SMS SY D040220083070S 1
C364 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C369 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C370 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C371 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C372 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C374,375 00D9639006557 C,ELECT GE 85C 220UF-M/6.3V,5*11-5RE-SHL SY D040221081060S 1
C376-379 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C388-391 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C401 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C402 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C403 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C404 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C405 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C406 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C407 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C408 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C409 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C410 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C411 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C412 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C413 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C414 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C415 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C417 00D9609009940 C,ELECT GE 85C 1000UF-M/16V,10*16-L.BLK SY D040102083030S 1
C418,419 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C420 963134001860S C,ELECT GE 85C 470UF-M/16V,8*11.5-5RE,SHL-SY D040471083080S 1
C421 00D9609009940 C,ELECT GE 85C 1000UF-M/16V,10*16-L.BLK SY D040102083030S 1
C422 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C423 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C424 00D2544541939 C,ELECT GE 85C 47UF-M/25V 5*11-5RE.SMS SY D040470084070S 1
C425 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C426 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C428-431 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C432 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C433 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C434 00D2544573981 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C435 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C436,437 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C438 00D2544573981 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C439 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C440 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C441 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C442 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C444 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C445 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C447 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C448,449 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C450,451 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C452 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C453 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C454 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C456 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C457 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C458 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C459 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C460 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C461 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C462 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C463 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C464 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C465 00D9639006544 C,ELECT GE 85C 22UF-M/25V,5*11-5RE SMS SY D040220084050S 1
C466 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C467 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C468 00D9630293602 C,ELECT GE 85C 1UF-M/50V,5*11-5RE.SMS SY (Pb Free) D040010087150S 1
C469 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C470 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C471 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C473 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C474,475 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C546 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C551 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C702 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C703,704 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C705 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
C706 nsp C,CERAMIC CHIP HIK Y5V1UF-Z/50V-1608REEL D011105597160S 1
C707 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C711,712 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C713-715 nsp C,CERAMIC CHIP HIK Y5V0.1UF-Z/50V-1608REEL D011104597160S 1
6

Denon RCD-N8 Specifications

General

Remotely operated	Yes
Security algorithms	WPS
Supported radio bands	FM, VHF
Built-in storage media	No
Audio formats supported	MP3
Internet radio services supported	iDevice, iTunes
Network streaming services supported	-
Product color	White
RMS rated power	130 W
Wi-Fi standards	802.11b, 802.11g
Digital audio optical out	1
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	50 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4000 g
