Denon RCD-N8 Service Manual

MAIN
Ref. No. Part No. Part Name Remarks Q'ty New Ver
C716 nsp C,CERAMIC CHIP HIK X7R1000PF-K/50V-1608REEL D011102777160S 1
C751-758 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C760 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C761-763 00D9630338606 C,ELECT CHIP(GE) 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 1
C764,765 00D2544573981 C,ELECT GE 85C 10UF-M/50V,5*11-5RE.SMS SY D040100087070S 1
C766-768 00D9630338606 C,ELECT CHIP(GE) 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 1
C769 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C770 00D9630333203 C,ELECT GE 85C 100UF-M/16V,5*11-5RE,SHL SY D040101083090S 1
C771 00D9630338606 C,ELECT CHIP(GE) 10UF-MVG/16V,3.3*3.7*5.2 REEL (Z8154) SY D050100083470S 1
C772,773 nsp C,CERAMIC CHIP HIK X7R)1UF-K/16V-1608REEL D011105173161S 1
C780 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C781 963134000450S C,ELECT CHIP(GE) 100UF-MVG/16V,6.6*7.2*5.7 REEL (Z8157) SY D050101083660S 1
C782 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C901 963134000450S C,ELECT CHIP(GE) 100UF-MVG/16V,6.6*7.2*5.7 REEL (Z8157) SY D050101083660S 1
C902 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C903 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C904 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C905 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C906,907 nsp C,CERAMIC CHIP T.C COG470PF-J/50V-1608REEL D010471167160S 1
C908 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C909,910 nsp C,CERAMIC CHIP HIK X7R0.047UF-K/16V-1608REEL D011473773160S 1
C911 963134000450S C,ELECT CHIP(GE) 100UF-MVG/16V,6.6*7.2*5.7 REEL (Z8157) SY D050101083660S 1
C912,913 00D2544302974 C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C915 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C916 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C917 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C918,919 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C920 00D2544302974 C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C921 nsp C,CERAMIC CHIP HIK X7R5600PF-K/50V-1608REEL D011562777160S 1
C922 963134000450S C,ELECT CHIP(GE) 100UF-MVG/16V,6.6*7.2*5.7 REEL (Z8157) SY D050101083660S 1
C923 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C924,925 00D2544302974 C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C926,927 nsp C,CERAMIC CHIP T.C COG15PF-J/50V-1608REEL D010150167160S 1
C928-931 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C932,933 00D2544302974 C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C934 nsp C,CERAMIC CHIP HIK X7R 0.033UF-K/25V-1608REEL D011333774161S 1
C935,936 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C937 963134000450S C,ELECT CHIP(GE) 100UF-MVG/16V,6.6*7.2*5.7 REEL (Z8157) SY D050101083660S 1
C938 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C939 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C940,941 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C942 00D2544302974 C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C943,944 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C945 963134000450S C,ELECT CHIP(GE) 100UF-MVG/16V,6.6*7.2*5.7 REEL (Z8157) SY D050101083660S 1
C946 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C947 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C948 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C951 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C952 nsp C,CERAMIC CHIP HIK X7R0.015UF-K/50V-1608REEL D011153777160S 1
C953 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C954 nsp C,CERAMIC CHIP HIK X7R4700PF-K/50V-1608REEL D011472777160S 1
C955,956 963134502200S C,ELECT CHIP(GE) 470UF-M/16V,10*10 MV 16VC470 SY D050471083471S 1
C957 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C959 00D2544302974 C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C960 nsp C,CERAMIC CHIP HIK X7R2200PF-K/50V-1608REEL D011222777160S 1
C962,963 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C965 nsp C,CERAMIC CHIP HIK X7R0.015UF-K/50V-1608REEL D011153777160S 1
C966 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C967 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C968-970 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C971 nsp C,CERAMIC CHIP T.C COG47PF-J/50V-1608REEL D010470167160S 1
C973 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C975,976 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C978 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C980 00D2544302974 C,ELECT GE 85C 100UF-M/10V,6.3*5-5RE SY (Pb Free) SY D040101082130S 1
C981 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C985-989 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C990 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C991 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C994 963134502200S C,ELECT CHIP(GE) 470UF-M/16V,10*10 MV 16VC470 SY D050471083471S 1
C995 nsp C,CERAMIC CHIP HIK X7R0.1UF-K/50V-1608REEL D011104577160S 1
C996 nsp C,CERAMIC CHIP HIK X7R)1UF-K/16V-1608REEL D011105173161S 1
OTHERS PARTS GROUP
CN101 nsp CN,WIRE 260MM/6P 5264-06=CKM2509HV-06 WH1007#22 L000261060080S 1
CN303 nsp CN,WIRE 2MM 200MM/7P 20010HS-07=CKM2002HR-07 RD2725#28 TUBE L002201070080S 1
CN401 nsp CN.FPC 1.0MM 1.0-11-29P ST DIP L130100112910S 1
CN408 nsp CN,WIRE 2MM 130MM/15P 20010HS-15=CKM2002HV-15 BK1007#24 L002131150180S 1
CN902 nsp CN,WIRE 2MM 100MM/6P 20010HS-06=CKM2002HV-06 WH20080#28 L002101060200S 1
CN903 nsp CN,WIRE 2MM 120MM/5P 20010HS-05=CKM2002HV-05 RD1007#26 L002121050190S 1
CP104 nsp CN.WAFER 2.0MM 20010WS-07A00 DIP7P STRAIGHT L101200100710S 1
CP201 nsp CN.WAFER C125Z1-29 29P BtoB HEADER(MALE) P=1.25MM L109012512920S 1
CP301 nsp CN.WAFER 2.0MM 20010WS-06A00 DIP6P STRAIGHT L101200100610S 1
CP302 nsp CN.WAFER C125Z2-29 29P BtoB SOCKET(FEMALE) P=1.25MM L109012522920S 1
CP303 nsp CN.WAFER 2.0MM 20010WS-07A00 DIP7P STRAIGHT L101200100710S 1
CP304 nsp CN.FPC 1.0MM 1.0-16-7PB-2 7P ST SMT (JSY) L130100160730S 1
CP403 nsp CN.FPC 1.0MM 1.0-9-4P ST JSY L130100090410S 1
CP404 nsp CN.FPC 1.0MM 1.0-11-7P ST DIP L130100110710S 1
CP701 963644101590S PIN,TER.MALE MFI514S0117 SMD IPOD DOCK (DENON SAGUB) L15015630A310S 1
CP901 nsp CN.FPC 1.0MM 10022HS-16C 16P VERTICAL SMT NON ZIF TYPE L130100220160S 1
GPT101 nsp TERMINAL MET37-0002/TAPIG EARTH FITTING 3790040886000S 1
GPT103-105 nsp TERMINAL MET37-0002/TAPIG EARTH FITTING 3790040886000S 1
J101,102 nsp CN,WIRE 1P JUMPER (0.6/52MM) L045084006040S 1
JACK101 00D9630237503 MODULE JSR1165/OPTICAL RECEIVER 96K SHUTTER E100116500040S 1
JACK102 00D9630132103 TER,RCA 4PIN RCA-405B-04(WH,WH,RD,RD)-YUQIU G602405B0400YS 1
JACK104 00D9630146005 TER,RCA 1PIN RCA-107A(BK) G600107A0000YS 1
JACK105 963646100500S
TER,BOARD SCREW 4P JB-405EWG-02(2RD/BK) 투명
G612405EWG02YS 1
JACK301 963643100130S JACK,MODULAR RJ45 1*1W/TRANSFORMER W/O LED 99TA-03188400023101 G4060RJ450120S 1
L104-107 963115100320S COIL,BEAD CBW201209U221T 220ohm SMD2012 TYPE D340201202210S 1
L108,109 nsp COIL,INDUCTOR POWER INDUCTOR 7W14L-100M-RE(10UH*2) SAGAMI D310701401010S 1
L110 nsp COIL,BEAD HB-1T2012-102JT SMD2012 TYPE D340201200090S 1
L302-304 963115100320S COIL,BEAD CBW201209U221T 220ohm SMD2012 TYPE D340201202210S 1
L305-307 nsp COIL,INDUCTOR NR8040T 4R7N 8*8 SMD D310804064720S 1
L308,309 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
L311 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
L312-314 nsp COIL,BEAD BLM18BD102SN1D 1000ohm 100mA SMD1608 REEL D340160831020S 1
L701 963115100320S COIL,BEAD CBW201209U221T 220ohm SMD2012 TYPE D340201202210S 1
L781-783 963115100320S COIL,BEAD CBW201209U221T 220ohm SMD2012 TYPE D340201202210S 1
L785-788 nsp COIL,BEAD HB-1T1608-102JT 1000ohm SMD1608 TYPE D340160821020S 1
L901-906 nsp COIL,BEAD CBW160808U121T 120ohm SMD1608 TYPE D340160811210S 1
L907 nsp COIL,FILTER-INDUCTOR 10UH-Q40/24M-R2.5-52RE 02TB D330100700520S 1
RES401 00D9630217701 RESONATOR,CERAMIC ZTT12.00MT-TF C1,C2=22PF 3PIN 2.5-REEL E830120000060S 1
7

Denon RCD-N8 Specifications

General

Remotely operated	Yes
Security algorithms	WPS
Supported radio bands	FM, VHF
Built-in storage media	No
Audio formats supported	MP3
Internet radio services supported	iDevice, iTunes
Network streaming services supported	-
Product color	White
RMS rated power	130 W
Wi-Fi standards	802.11b, 802.11g
Digital audio optical out	1
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	50 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4000 g
