Denon RCD-N8 Service Manual

MAIN
Ref. No. Part No. Part Name Remarks Q'ty New Ver
SW401 963662100130S SW,TACT THHH583RAA VERTICAL TACT SWITCH 260G G180583000010S 1
U100 nsp CN.WAFER 2.5MM FEMALE HEADER 2.54MM 64P(2*32) CSHA201-3202 DUAL L102201640200S 1
X901 963141100070S CRYSTAL 16.934MHZ HC-49/SMD CL=12PF E80016R934030S 1
XTAL101 963141100770S CRYSTAL CHIP 24.576MHz CL=10PF FA-238/SMD3225 EPSON E80524R576050S 1
XTAL102 963141100770S CRYSTAL CHIP 13.5MHz CL=10PF FA-238V/SMD3225 EPSON E80513R500050S 1
BKT101 nsp BRACKET AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
BKT301,302 nsp BRACKET AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
★
963189100410D
CX870-3B-D60 JUKEBOX NETWORK 2ANT 64MSDRAM NEW F/W (E2) RCDN8
8.9528E+12 1 *
★
963189100420D
CX870-3B-D60 JUKEBOX NETWORK 2ANT 64MSDRAM NEW F/W (JP) RCDN8
8.9528E+12 1 *
★
963189100500S
CX870-3B-D60 JUKEBOX NETWORK 2ANT 64MSDRAM NEW F/W (E1C) RCDN8
8.9525E+12 1 * Ver.3
★
nsp HEAT SINK DRAF109SP AL6063 77*16*(H)49(ANAM:CMY1A368)/MAIN 2120212118000S 1
★
nsp PLATE DRAF109SP(DENON) SPTE t0.3 A4/TERMINAL 4470212666000S 1
★
nsp SCREW,TAP TITE +2S 3*8 B-TYPE ZNW/BH B020030081B10S 3
★
943183100210S TUNER,FM KST-MW104FV1-S63V 4GANG+FM ONLY+50US+RDS E2 E900104011630S 1
★
963183100300S TUNER,FM/AM KST-MW004MV1-S63 JP E903004100020S 1
8

Denon RCD-N8 Specifications

General

Remotely operated	Yes
Security algorithms	WPS
Supported radio bands	FM, VHF
Built-in storage media	No
Audio formats supported	MP3
Internet radio services supported	iDevice, iTunes
Network streaming services supported	-
Product color	White
RMS rated power	130 W
Wi-Fi standards	802.11b, 802.11g
Digital audio optical out	1
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	50 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4000 g
