Denon RCD-N8 Service Manual

49
2.5.AnalogIn1/2
2.6. Digital In
Check Analog Audio Signal from AUX1/AUX2.
MAIN B'D
• [AUX1], [AUX2] input
Check Power Supply Voltages for OPTICAL Input IC.
MAIN B'D
• [JACK101] : 3pin +3V3_D1
• [IC401] : 3pin +3V3_D1
• [IC701] : 6,11pin : AUX1_L/R
: 4,13pin : AUX2_L/R
: 5,7pin : AIN_CNT1/2
[L,H](AUX-1), [H,L](AUX-2)
Check Digital Audio Data from OPTICAL Input IC.
MAIN B'D
• [IC103] : 28pin OPT_IN
Check the input of DIR
（☆ 2）
• [IC103] : 47,48 : AIN_L / AIN_R
OK
OK
OK
OK
OK
Check Soldering.
• [JACK102] on MAIN B'D
Check Soldering.
• [JACK101] : 3pin +3V3_D1
• [IC401] : IN : +5V_SMPS1 / OUT : +3V3_D1
• [CN408] : 9pin +5V_SMPS1
• SMPS B'D
Check Soldering.
（☆ 1）
• [IC403] : 69,70pin AIN_CNT1/2
Check Soldering.
• [IC103] OPT_IN on MAIN B'D
Check Soldering.
（☆ 3）
• [C125],[C124] on MAIN B'D
NG
NG
NG
NG
NG
to 2.2. CD PLAY
z
Mark
to 2.2. CD PLAY
z
Mark

Denon RCD-N8 Specifications

General

Remotely operated	Yes
Security algorithms	WPS
Supported radio bands	FM, VHF
Built-in storage media	No
Audio formats supported	MP3
Internet radio services supported	iDevice, iTunes
Network streaming services supported	-
Product color	White
RMS rated power	130 W
Wi-Fi standards	802.11b, 802.11g
Digital audio optical out	1
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	50 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4000 g
