Denon RCD-N8 Service Manual

50
2.7 . USB/iPod Dock/ETHERNET/WiFi
Check Power Supply Voltages for Network.
Network B'D
• [CP302] : 24,25pin : +5V_NET
• [CP302] : 28,29pin : +5V_VBUS
Check Power Supply Voltages for USB.
Network B'D
• [CP301] : 5,6pin +5V
Check Power Supply Voltages for iPodDock.
Network B'D
• [CP303] : 1pin +5V
Check Power Supply Voltages for CX870.
Network B'D
• [IC306] : 3pin NET_ +3V3
• [IC307] : 3pin NET_ +1V9
• [IC308] : 3pin NET_ +1V2
• [CP302] : 16pin E_P_CONT "H" level O.K.?
Check Reset signal for ETHERNET B'D (CX870)
Network B'D
• [CP302] : 15pin E_RESET
"H" level O.K.?
Check Digital Audio Data for CODEC.
Network B'D
• [CP302] : 6pin CX870_SPDIF
MAIN B'D
• [CP201] : 24pin CX870_SPDIF
OK
OK
OK
OK
OK
OK
Check Soldering.
Network B'D
• [CP302] : 24,25pin : +5V_NET
• [CP302] : 28,29pin : +5V_VBUS
MAIN B'D
• [CP201] : 5,6pin : +5V_NET
• [CP201] : 1,2pin +5V_VBUS
• [CN408] : 10pin : +5V_NET
• [CN408] : 11,12pin : +5V_SMPS2
• SMPS B'D
Check Soldering.
• [CP301] : 5,6pin +5V on Network B'D
• [CN641] : 1,2pin +5V on DISPLAY B'D
• [JACK641] on DISPLAY B'D
Check Soldering.
• [CP303] : 1pin +5V on ETHERNET B'D
• [CN303] : 1pin +5V on iPodDock B'D
• [CP701] on iPodDock B'D
Check Soldering.
• [IC306] on Network B'D
• [IC307] on Network B'D
• [IC308] on Network B'D
• [CP302] : 16pin on Network B'D
Check Soldering.
• [CP302] : 15pin E_RESET on Network B'D
• [CP201] : 15pin E_RESET on MAIN B'D
Check Soldering.
• [CP302] : 6pin CX870_SPDIF on Network B'D
• [CP201] : 24pin CX870_SPDIF on MAIN B'D
NG
NG
NG
NG
NG
NG
to 2.2. CD PLAY
