Denon RCD-N8 Service Manual

FRONT
PARTS LIST OF P.W.B. UNIT
FRONT P.W.B. UNIT ASS'Y
NOTE: The symbols in the column "Remarks" indicate the following destinations.
E2 : Europe model E3 : US & Canada model JP : Japan model E1C : China model
Ref. No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D601 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D631,632 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D661 963202500260S D,ZENER CHIP 0.2W 2.7V UDZV SERIES (UMD2 TYPE) K06602R76P400S 1
Q601,602 00D9600296309 SEMI,CHIP TR/NPN 2SC KRC111S (NM) 0.2W/SOT-23 REEL J522011100210S 1
LD601 963263100700S LED,ROUND WEJ3PBWW-C02-ZD 3PI WHITE P=2.54 BULK K500039001110S 1
LD602 963263100510S LED,ROUND WEJ3290W-R2H0-BA 3PI RED/YELLOW GREEN BI-COLOR K500032451010S 1
RESISTORS GROUP
R601 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R602 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 1
R604 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R605 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R606 nsp R,CHIP THICK 110-J,1/16W-1608REEL C20001116M160S 1
R608 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 1
R609 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R610 nsp R,CHIP THICK 270-J,1/16W-1608REEL C20002716M160S 1
R611 nsp R,CHIP THICK 180-J,1/16W-1608REEL C20001816M160S 1
R612 nsp R,CHIP THICK 270-J,1/16W-1608REEL C20002716M160S 1
R613 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 1
R614 nsp R,CHIP THICK 180-J,1/16W-1608REEL C20001816M160S 1
R615 nsp R,CHIP THICK 270-J,1/16W-1608REEL C20002716M160S 1
R616 nsp R,CHIP THICK 150-J,1/16W-1608REEL C20001516M160S 1
R617 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R644 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
R647,648 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R649,650 nsp R,CHIP THICK 470-J,1/16W-1608REEL C20004716M160S 1
R651,652 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R653 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R661 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R662 nsp R,CHIP THICK 1M-J,1/16W-1608REEL C20001056M160S 1
R663 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
CAPACITORS GROUP
C388-391 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C601-605 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C631,632 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C633,634 nsp C,CERAMIC CHIP HIK X7R0.027UF-K/50V-1608REEL D011273777163S 1
C641 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C643 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C645,646 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C647 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C654-657 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C658 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C659 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C661 00D9630333300 C,ELECT GE 85C 47UF-M/16V,6.3*5-5RE.SRE SY D040470083070S 1
C662 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C663 nsp C,CERAMIC CHIP HIK Y5V1UF-Z/50V-1608REEL D011105597160S 1
C664 nsp C,CERAMIC CHIP HIK X7R)4.7UF-K/6.3V-1608REEL D011475571160S 1
C665 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C666 00D9630130202 C,ELECT GE 85C 10UF-M/35V,5*5-5RE.SY D040100085070S 1
C667 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C668,669 nsp C,CERAMIC CHIP HIK Y5V1UF-Z/50V-1608REEL D011105597160S 1
C670 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C671 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C672 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C673 nsp C,CERAMIC CHIP HIK X7R0.01UF-K/50V-1608REEL D011103777160S 1
C674 nsp C,CERAMIC CHIP HIK X7R)0.1UF-K/25V-1608REEL D011104774161S 1
C675 00D9630130202 C,ELECT GE 85C 10UF-M/35V,5*5-5RE.SY D040100085070S 1
C676,677 nsp C,CERAMIC CHIP HIK X5R)4.7UF-K/25V-2012REEL GRM21BR61E475KA12L MURATA D011475774200S 1
C678-680 nsp C,CERAMIC CHIP T.C COG47PF-J/50V-1608REEL D010470167160S 1
C681 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C682 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
C683 nsp C,CERAMIC CHIP T.C COG100PF-J/50V-1608REEL D010101167160S 1
C684 nsp C,CERAMIC CHIP T.C X7R 1000PF-K/50V-1608REEL D010102777160S 1
OTHERS PARTS GROUP
BKT3-5 nsp BRACKET AVR133(HARMAN) BURRING HOLE SPTE 0.8t/SCREW 4010210196100S 1
CLP301 nsp CLAMP HMX9800(ON)(HAITAI) (W=2.6,L=50)/WIRE(SOLDER) 4330000120000S 1
CN641 nsp CN,WIRE 2MM 280MM/6P 20010HS-06=CKM2002HV-06 RD2725#24,28 SHLD L002281060190S 1
CN661 nsp CN.FPC 1.0MM 1.0-11-29P ST DIP L130100112910S 1
CP305 nsp CN.WAFER C125Z2-29 29P BtoB SOCKET(FEMALE) P=1.25MM L109012522920S 1
CP306 nsp CN.WAFER C125Z1-29 29P BtoB HEADER(MALE) P=1.25MM L109012512920S 1
CP631 nsp CN,WIRE 2MM 250MM/7P 20010HS-07=CKM2002HV-07 RD2725#26 SHLD L002251070190S 1
CP661 nsp CN.FPC 1.0MM 1.0S-12X-30PW 30P AN DIP BOTTOM CONTACT L130100123020S 1
J610 nsp BEAD,COIL BFS 3550AOL 3.5*5.0 AXIAL 52REEL 7610035500040S 1
J620 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
J638 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
JACK641 963649010300S CN,PLUG CONTACT USB A TYPE FEMALE DIP4P BK USBAS-00401B014-G G480040101410S 1
JK631,632 963643102240S JACK,D3.5 HTJ035-18AB(SILVER) G401035180020S 1
L650-655 nsp COIL,BEAD HB-1T1608-102JT 1000ohm SMD1608 TYPE D340160821020S 1
L661,662 nsp COIL,BEAD CBW201209U121T 120ohm SMD2012 TYPE D340201221210S 1
RMC601 963262011220S MODULE,REMOCON R34FS8A 38KHZ IR REMOCON MODULE P=2.54MM H=11MM E940348003810S 1
S601-610 00D9630095305 SW,TACT SKHV10910D01 KB581/LG 160G G180040500010S 1
★ nsp P.C.B RCDN8 330*247 FR1 ARRY(2) 1.6T/FRONT 7020072650000S 1
★ nsp
SUPPORTER DRAN5WTE2￠4.0*1(H) KangYang LEDS-1 /LED
4070212213000S 1
1

Denon RCD-N8 Specifications

General

Remotely operated	Yes
Security algorithms	WPS
Supported radio bands	FM, VHF
Built-in storage media	No
Audio formats supported	MP3
Internet radio services supported	iDevice, iTunes
Network streaming services supported	-
Product color	White
RMS rated power	130 W
Wi-Fi standards	802.11b, 802.11g
Digital audio optical out	1
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	50 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4000 g
