Denon RCD-N8 Service Manual

MAIN
PARTS LIST OF P.W.B. UNIT
MAIN P.W.B. UNIT ASS'Y
NOTE:
The symbols in the column "Remarks" indicate the following destinations.
E2 : Europe model E3 : US & Canada model JP : Japan model E1C : China model
Ref. No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D103,104 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D105 00D2760846900 D,SCHOTTKY RB060M-30 SCHOTTKY BARRIER DIODE 3516 REEL K120060300010S 1
D106 00D9630328409 D,SWITCHING 1N4007 52REEL 1000V 1A K000400700010S 1
D108-115 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D282 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D283 00D9630328409 D,SWITCHING 1N4007 52REEL 1000V 1A K000400700010S 1
D284 00D2760846900 D,SCHOTTKY RB060M-30 SCHOTTKY BARRIER DIODE 3516 REEL K120060300010S 1
D285 00D9630328409 D,SWITCHING 1N4007 52REEL 1000V 1A K000400700010S 1
D286 00D2760846900 D,SCHOTTKY RB060M-30 SCHOTTKY BARRIER DIODE 3516 REEL K120060300010S 1
D287,288 00D9630328409 D,SWITCHING 1N4007 52REEL 1000V 1A K000400700010S 1
D401,402 00D9630328409 D,SWITCHING 1N4007 52REEL 1000V 1A K000400700010S 1
D403,404 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D405 nsp D,SWITCHING CHIP 1SS355USM(A) K005035500010S 1
D406,407 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D705 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D901 00D9630355401 D,SWITCHING CHIP KDS4148U FAST SWITCHING SOD-323(USC) K005041480030S 1
D902 nsp D,SWITCHING CHIP 1SS355USM(A) K005035500010S 1
IC102 963239007790M IC,LINEAR-REGULATOR IL1117_5.0 SOT-223 5.0V 1A LOW DROPOUT J126111750010S 1
IC103 23681014050AS IC,LOGIC-INTERFACE PCM9211 TRANSCEIVER LQFP48 J046921100010S 1
IC104 963231101310S IC,LINEAR-REGULATOR KIA78R33F 3.3V LOW DROP 1A DPAK-5 J12678R330050S 1
IC108 00MHC12273370 IC,ANALOG TAS5508CPAGR TQFP64 8CH DIGIT AUDIO PWM PROCESSOR J080550800010S 1
IC110 00D2630995004 IC,LINEAR OP AZ4580MTR-E1 CU(C1:A~J) SOIC-8P OP AMP J121458001020S 1
IC114 00D2630995004 IC,LINEAR OP NJM4556AM HEADPHONE AMP DMP8 300MW J121455600010S 1
IC118 00D2623503911 IC,ANALOG TAS5142DKDR PSOP36 STEREO DIGITAL AMP POWER STAGE J080514200010S 1
IC282 00D2631213905 IC,LINEAR-REGULATOR KIA7808AF 8V 1A DPAK J126780800250S 1
IC301 23681012450AS IC,LINEAR-DRIVER NCP380HMU15AATBG UDFN6 J127380150010S 1
IC303,304 963233100050S IC,LOGIC TC7USB221FT(EL,M) USB SW TSSOP14 J040702215510S 1
IC306-308 963231101300S IC,LOGIC-D/D CONVER AP3503E 340kHz 3A DC-DC BUCK CONVERTER PSOP8 J048350300010S 1
IC309 nsp IC,LOGIC-DECODER MFI337S3959 COPROCESSOR(IPOD) DENON SAGUB J044337395910S 1
IC310 23681012450AS IC,LINEAR-DRIVER NCP380HMU15AATBG UDFN6 J127380150010S 1
IC401 963231101310S IC,LINEAR-REGULATOR KIA78R33F 3.3V LOW DROP 1A DPAK-5 J12678R330050S 1
IC402 00D2631242905 IC,LINEAR-REGULATOR NJM2831F33 3.3V 0.13A LDO WITH ON/OFF SOT-23-5P J126283133010S 1
IC403 963243101500S R5F56108VNFP RCD-N8 E2/JP E2,JP 8952500000060 1 * Ver.4
IC403 963243101480S R5F56108VNFP RCD-N8 E1C E1C 8952500000070 1 * Ver.4
IC404 963239100780S IC,LINEAR-RESET NCP300LSN30T1 TSOP-5 J125030050010S 1
IC405 943239100720S IC,MEMORY-EEPROM R1EX24256BSAS0A 256Kbit SERIAL SOP8 RENESAS J000242565570S 1
IC406 00MHC12252090 IC,LINEAR-REGULATOR NJM2387ADL3 1A 0.2V TO252-5 LOW DROP VOL REGULATOR J126238700010S 1
IC701 963239100920S IC,LOGIC-INTERFACE NJM2755V/SSOP16 4-IN/1-OUT STEREO AUDIO SELECTOR J046275505310S 1
IC901 963231101210S IC,LINEAR-REGULATOR IL1117-1.5 SOT-223 1.5V 1A LOW DROPOUT J126111715070S 1
IC902 245010015000S IC,LOGIC-DECODER TC94A92FG-301 LQFP80 CD HEAD AMP AND AUDIO DECODER J044949200010S 1
IC903 23981000350AS IC,LINEAR-DRIVER IP4001CR 28SSOPH-375 TUBE 5CH MOTOR DRIVE 5V REG J127400100010S 1
Q105 00D9630121606 SEMI,CHIP TR/NPN 2SC KRC107S (NH)/SOT-23 REEL J522107S00210S 1
Q106 90M-BA001600R SEMI,CHIP TR/PNP 2SA KRA107S (PH) /SOT-23 REEL J5200107S0050S 1
Q107 00D9630121606 SEMI,CHIP TR/NPN 2SC KRC107S (NH)/SOT-23 REEL J522107S00210S 1
Q108 90M-BA001600R SEMI,CHIP TR/PNP 2SA KRA107S (PH) /SOT-23 REEL J5200107S0050S 1
Q110,111 00D2690192902 SEMI,CHIP TR/NPN 2SC KRC102S (NB) 0.2W/SOT-23 REEL J522010200210S 1
Q112,113 90M-BA001600R SEMI,CHIP TR/PNP 2SA KRA107S (PH) /SOT-23 REEL J5200107S0050S 1
Q114,115 00D2690192902 SEMI,CHIP TR/NPN 2SC KRC102S (NB) 0.2W/SOT-23 REEL J522010200210S 1
Q116 00D9630066606 SEMI,CHIP TR/NPN 2SC KTC3875Y(ALY) 0.15W/SMT-REEL J5223875Y0210S 1
Q117,118 00D9630148508 SEMI,CHIP TR/PNP 2SA KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 1
Q119 00D9630066606 SEMI,CHIP TR/NPN 2SC KTC3875Y(ALY) 0.15W/SMT-REEL J5223875Y0210S 1
Q120-125 00D2730460905 SEMI,CHIP TR/NPN 2SC KTC2875B(MB) 0.15W/LOW-ON-RES SOT23(RTK) J5222875B0010S 1
Q126 90M-BA001600R SEMI,CHIP TR/PNP 2SA KRA107S (PH) /SOT-23 REEL J5200107S0050S 1
Q127 00D9630121606 SEMI,CHIP TR/NPN 2SC KRC107S (NH)/SOT-23 REEL J522107S00210S 1
Q303 00D2690184907 SEMI,CHIP TR/PNP 2SA KRA102S(PB) 0.2W/SOT-23 REEL J520010200210S 1
Q304 00D2690192902 SEMI,CHIP TR/NPN 2SC KRC102S (NB) 0.2W/SOT-23 REEL J522010200210S 1
Q403 00D2690192902 SEMI,CHIP TR/NPN 2SC KRC102S (NB) 0.2W/SOT-23 REEL J522010200210S 1
Q405 00D2690192902 SEMI,CHIP TR/NPN 2SC KRC102S (NB) 0.2W/SOT-23 REEL J522010200210S 1
Q406 00D2690184907 SEMI,CHIP TR/PNP 2SA KRA102S(PB) 0.2W/SOT-23 REEL J520010200210S 1
Q701 00D2690192902 SEMI,CHIP TR/NPN 2SC KRC102S (NB) 0.2W/SOT-23 REEL J522010200210S 1
Q901 00D9630148508 SEMI,CHIP TR/PNP 2SA KTA1504S-Y 0.15W SOT-23 REEL J520015040150S 1
RESISTORS GROUP
R101-104 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R105 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R106 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R109 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R111 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R114 nsp R,CHIP THICK 1M-J,1/16W-1608REEL C20001056M160S 1
R115 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R116-118 nsp R,CHIP THICK 47-J,1/16W-1608REEL C20004706M160S 1
R119 nsp R,CHIP THICK 680-J,1/16W-1608REEL C20006816M160S 1
R120 nsp COIL,BEAD HB-1M1608-301JT 300ohm SMD1608 TYPE D340160803010S 1
R122,123 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R131 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R132 nsp R,CHIP THICK 3.3-J,1/16W-1608REEL C2003R306M161S 1
R133 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R135 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R136,137 nsp R,CHIP THICK 200-J,1/16W-1608REEL C20002016M160S 1
R138 nsp R,CHIP THICK 2.2-J,1/16W-1608REEL C2002R206M160S 1
R139 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R140-142 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R143 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R144 nsp R,CHIP THICK 1-J,1/16W-1608REEL C20000106M160S 1
R145 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R146 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R147 nsp R,CHIP THICK 1M-J,1/16W-1608REEL C20001056M160S 1
R148-151 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R152 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R153 nsp R,CHIP THICK 22-J,1/16W-1608REEL C20002206M160S 1
R154-156 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R157 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R158 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R159 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R160,161 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R161 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R162 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R163 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R164,165 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
R166 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R167-171 nsp COIL,BEAD HB-1T1608-102JT 1000ohm SMD1608 TYPE D340160821020S 1
R172,173 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R174 nsp R,CHIP THICK 27K-J,1/16W-1608REEL C20002736M160S 1
R175-178
nsp
R,CHIP THICK 10-J,1/16W-1608REEL C20001006M160S 1
R179-182 nsp R,CHIP THICK 18-F,1/10W-2012REEL C200018040200S 1
