Denon RCD-N8 Service Manual

MAIN
Ref. No. Part No. Part Name Remarks Q'ty New Ver
R183-186 nsp R,CHIP THICK 3.3-J,1/16W-1608REEL C2003R306M161S 1
R187-190 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
R191 nsp R,FIXED,M.O. RSD-R0-1WJ-91 3.2*8.5 P=5MM SMALL R.REEL N113135691020S 1
R192,193 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
R194 nsp R,FIXED,M.O. RSD-R0-1WJ-91 3.2*8.5 P=5MM SMALL R.REEL N113135691020S 1
R195-200 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R201,202 nsp R,CHIP THICK 39K-J,1/16W-1608REEL C20003936M160S 1
R203 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R204,205 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R206 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R207 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R208 nsp R,CHIP THICK 10-J,1/16W-1608REEL C20001006M160S 1
R209-214 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R215,216 nsp R,CHIP THICK 39K-J,1/16W-1608REEL C20003936M160S 1
R217 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R218 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R219 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R220 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R221 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R222 nsp R,CHIP THICK 10-J,1/16W-1608REEL C20001006M160S 1
R223,224 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R225,226 nsp R,CHIP THICK 22K-J,1/16W-1608REEL C20002236M160S 1
R227,228 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R229,230 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R231 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R232 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R233 nsp R,CHIP THICK 4.7K-J,1/16W-1608REEL C20004726M160S 1
R234 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R235 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R238-243 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R244,245 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R246 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R247,248 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R249,250 nsp R,CHIP THICK 150K-J,1/16W-1608REEL C20001546M160S 1
R251 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R252,253 nsp R,CHIP THICK 150K-J,1/16W-1608REEL C20001546M160S 1
R254,255 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R274,275 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R276 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R277 nsp R,CHIP THICK 0-J,1/8W-3216REEL C200000061300S 1
R278-281 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R282-285 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
R286,287 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R288 nsp R,CHIP THICK 1-J,1/16W-1608REEL C20000106M160S 1
R289,290 nsp R,CHIP THICK 0-J,1/8W-3216REEL C200000061300S 1
R291,292 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
R293 nsp R,CHIP THICK 0-J,1/8W-3216REEL C200000061300S 1
R294-299 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
R300 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R302 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R304 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R305 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R306 nsp R,CHIP THICK 27K-J,1/16W-1608REEL C20002736M160S 1
R307
nsp
R,CHIP THICK 75K-J,1/16W-1608REEL C20007536M160S 1
R309 nsp R,CHIP THICK 120K-J,1/16W-1608REEL C20001246M160S 1
R311 nsp R,CHIP THICK 75K-J,1/16W-1608REEL C20007536M160S 1
R312 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R314 nsp R,CHIP THICK 27K-J,1/16W-1608REEL C20002736M160S 1
R315 nsp R,CHIP THICK 120K-J,1/16W-1608REEL C20001246M160S 1
R319-322 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R324,325 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R326 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R327 nsp R,CHIP THICK 3.9K-J,1/16W-1608REEL C20003926M160S 1
R328 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R329 nsp R,CHIP THICK 820K-F,1/16W-1608REEL C20008244M160S 1
R330 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R331 nsp R,CHIP THICK 3.9K-J,1/16W-1608REEL C20003926M160S 1
R332 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R333 nsp R,CHIP THICK 100K-F,1/16W-1608REEL C20001044M160S 1
R334 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R335 nsp R,CHIP THICK 3.9K-J,1/16W-1608REEL C20003926M160S 1
R336 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R339,340 nsp R,CHIP THICK 2.2K-J,1/16W-1608REEL C20002226M160S 1
R341-343 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R345-347 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R348 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R349 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R350,351 nsp R,CHIP THICK 33-J,1/16W-1608REEL C20003306M160S 1
R352 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R353 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R359-361 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R362,363 nsp R,CHIP THICK 75-J,1/16W-1608REEL C20007506M160S 1
R368 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R373 nsp R,CHIP THICK 12K-F,1/16W-1608REEL C20001234M160S 1
R374 nsp R,CHIP THICK 27K-F,1/16W-1608REEL C20002734M160S 1
R375 nsp R,CHIP THICK 3K-F,1/16W-1608REEL C20003024M161S 1
R376,377 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R378 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R380 nsp R,CHIP THICK 100K-J,1/16W-1608REEL C20001046M160S 1
R381 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R382 nsp R,CHIP THICK 100-J,1/16W-1608REEL C20001016M160S 1
R383 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R384 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R386,387 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
R388 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R389,390 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R391-393 nsp R,CHIP THICK 0-J,1/10W-2012REEL C200000060200S 1
R396 nsp R,CHIP THICK 0-J,1/8W-3216REEL C200000061300S 1
R401-404 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R407 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R409,410 nsp R,CHIP THICK 0-J,1/16W-1608REEL C20000006M160S 1
R412 nsp R,CHIP THICK 47K-J,1/16W-1608REEL C20004736M160S 1
R417 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R418 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S
1
R423 nsp
R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R424 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R426 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
R428 nsp R,CHIP THICK 10K-J,1/16W-1608REEL E2 C20001036M160S 1
R428 nsp R,CHIP THICK 6.8K-J,1/16W-1608REEL JP C20006826M160S 1
R429-432 nsp R,CHIP THICK 10K-J,1/16W-1608REEL C20001036M160S 1
R433 nsp R,CHIP THICK 1K-J,1/16W-1608REEL C20001026M160S 1
3

Denon RCD-N8 Specifications

General

Remotely operated	Yes
Security algorithms	WPS
Supported radio bands	FM, VHF
Built-in storage media	No
Audio formats supported	MP3
Internet radio services supported	iDevice, iTunes
Network streaming services supported	-
Product color	White
RMS rated power	130 W
Wi-Fi standards	802.11b, 802.11g
Digital audio optical out	1
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	50 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4000 g
