DERRICK HYPERPOOL SHAKER User Manual

PE-S-014-09
rev. 01/15/08
Derrick®, Flo-Line®, FLC 2000™, Flo-Line Scalper™, Pyramid®, Sandwich Screens®, DE-1000™, Hi-G™, Vacu-Flo™, GBG™, PMD™, PWP™, SWG™,
DC™, DF™, DX™, and GS™, are trademarks of Derrick Corporation.
(F:\ENG\DOCS\PES014.DOC)
RECOMMENDED THERMAL UNIT SELECTION TABLE
FOR DERRICK
®
SUPPLIED MANUAL STARTERS
DERRICK VIBRATING MACHINES
575V.A.C. 60Hz 1.5HP = SQD-B3.30 or FUR-H19
460V.A.C. 60Hz 1.5HP = SQD-B4.15 or FUR-H21
F, FX, K, KX, L, LX, T, TX 230V.A.C. 60Hz 1.5HP = SQD-B10.2 or FUR-H26
MOTORS 215V.A.C. 60Hz 1.5HP = SQD-B10.2 or FUR-H27
440V.A.C. 50Hz 1.5HP = SQD-B3.70 or FUR-H19
380V.A.C. 50Hz 1.5HP = SQD-B4.15 or FUR-H21
220V.A.C. 50Hz 1.5HP = SQD-B8.20 or FUR-H26
575V.A.C. 60Hz 2.5HP = SQD-B6.25 or FUR-H24
460V.A.C. 60Hz 2.5HP = SQD-B7.70 or FUR-H26
E, EX, M, MX, SG, SGX 230V.A.C. 60Hz 2.5HP = SQD-B17.5 or FUR-H32
MOTORS 215V.A.C. 60Hz 2.5HP = SQD-B17.5 or FUR-H32
440V.A.C. 50Hz 2.5HP = SQD-B6.90 or FUR-H24
380V.A.C. 50Hz 2.5HP = SQD-B7.70 or FUR-H26
220V.A.C. 50Hz 2.5HP = SQD-B14.0 or FUR-H31
575V.A.C. 60Hz 3.0HP = SQD-B6.90 or FUR-H25
460V.A.C. 60Hz 3.0HP = SQD-B9.10 or FUR-H27
R, RX 230V.A.C. 60Hz 3.0HP = SQD-B19.5 or FUR-H33
MOTORS 215V.A.C. 60Hz 3.0HP = SQD-B19.5 or FUR-H34
440V.A.C. 50Hz 3.0HP = SQD-B7.70 or FUR-H26
380V.A.C. 50Hz 3.0HP = SQD-B9.10 or FUR-H27
220V.A.C. 50Hz 3.0HP = SQD-B17.5 or FUR-H32
575V.A.C. 60Hz 5.0HP = SQD-B11.5 or FUR-H29
460V.A.C. 60Hz 5.0HP = SQD-B15.5 or FUR-H32
A, C, N 230V.A.C. 60Hz 5.0HP = SQD-B36.0 or FUR-H40
MOTORS 215V.A.C. 60Hz 5.0HP = SQD-B36.0 or FUR-H40
440V.A.C. 50Hz 5.0HP = SQD-B12.8 or FUR-H30
380V.A.C. 50Hz 5.0HP = SQD-B15.5 or FUR-H32
220V.A.C. 50Hz 5.0HP = SQD-B32.0 or FUR-H37
DERRICK DEGASSER
575V.A.C. 60Hz 5.0HP = SQD-B8.20 or FUR-H28
460V.A.C. 60Hz 5.0HP = SQD-B10.2 or FUR-H30
230V.A.C. 60Hz 5.0HP = SQD-B19.5 or FUR-H38
415V.A.C. 50Hz 5.0HP = SQD-B11.5 or FUR-H31
380V.A.C. 50Hz 5.0HP = SQD-B19.5 or FUR-H32
DERRICK PRIMER
575V.A.C. 60Hz 1.5HP = SQD-B3.30
460V.A.C. 60Hz 1.5HP = SQD-B3.70
230V.A.C. 60Hz 1.5HP = SQD-B8.20
380V.A.C. 50Hz 1.5HP = SQD-B3.70
NOTE: IF MOTOR VOLTAGE OR HORSE POWER IS NOT LISTED, CONTACT ENGINEERING
DEPARTMENT.
**** FOR MAGNETIC STARTER OVERLOAD INFO REFER TO THE ELECTRICAL PARTS
LIST THAT IS FOUND ON THE EQUIPMENTS GENERAL ARRANGEMENT DRAWING.
