INSTALLATION
15 Jun 12 3-5
HyperPoolShaker
DESILTER AND DESANDER INSTALLATION
While the HyperPool mud cleaner is fully assembled and tested prior to shipment, shipping
restrictions that limit the overall height of equipment often require separation of the desilter and
desander for shipment. The units are then skid-mounted for shipment with the basic machine.
Refer to Section 4 for operating information on the desander and desilter.
Desilter Installation
Required Equipment
1. A suitable lifting device is required for lifting and positioning the unit. Weights of machine-
mounted round desilters are as follows:
14-Way 1650 lbs (748 kg)
16-Way 1700 lbs (773 kg)
20-Way 1800 lbs (818 kg)
2. In addition, 3/4” and a 7/8” wrenches are required.
Installation Procedure
Prior to installing the desilter, visually inspect the assembly for any signs of damage. If unit
appears to be damage free, proceed as follows:
WARNING! TO ENSURE PROPER BALANCE AND ORIENTATION WHEN UNIT
IS RAISED AND PREVENT DAMAGE TO COMPONENTS, ATTACH LIFTING
SLING ONLY AT DESIGNATED LIFT POINTS.
WARNING! BE SURE THAT HANDLING DEVICES HAVE SUFFICIENT LIFTING
CAPACITY TO SAFELY HANDLE THE WEIGHT OF THE EQUIPMENT.
1. Note location of facility discharge pipe to be connected to desilter. If necessary to
accommodate piping, re-locate Victaulic
®
cap to opposite end of desilter discharge pipe.
Note! Confirm that facility piping corresponds with desilter discharge pipe
before proceeding with installation.
2. Attach overhead lifting device to both LIFT points (Figure 3-3).
3. Remove and retain hardware securing desilter to skid-mounted shipping brackets. Do not
remove shipping brackets from skid. Retained hardware consists of the following parts:
1/2-13 x 1-3/4” Hex Head Bolt
Note! Retained hardware will be used to attach the desilter to the collection
pan.
