DERRICK HYPERPOOL SHAKER User Manual

SECTION 7 - SGX VIBRATOR MOTOR
15 Jun 12 7-1
HyperPoolShaker
DESCRIPTION
Motion is generated by dual explosion-proof SGX vibrator motors and transmitted to the screen
frame to separate and conveys solids over the screen panels. The SGX motor is rated for
continuous duty with Totally Enclosed Non-Ventilated (TENV) construction and permanently
lubricated, sealed bearings.
Eccentric weights installed on the rotor shaft produce the motor’s vibratory action. The weight,
which is measured in in-lbs, varies depending on the application and is stamped on the motor
nameplate. The two vibrator motors are connected to cause the motors to rotate in opposite
directions to produce linear motion.
The vibrator motors must be operated at their rated three-phase supply voltage. The model
designation shown on the nameplate is defined as follows:
SG X 30 – 18 – 460/480 – 6 000
Factory-Assigned Options Code
Supply Voltage Frequency
5 - 50Hz
6 - 60Hz
Operating Voltage
RPM (x 100)
Eccentric Weight (in
-lbs)
per Side
Construction:
X - Explosion-Proof
Motor Type
:
SG
- Super G Motor
