Technical Specification - CONFIDENTIAL - Page 20 of 21
DESKO ICON Scanner
®
Doc # 7 001 140 101 Doc.-Rev.: 2016-11-09
13.2 Special Integration Rules
To avoid problems concerning the integration and to achieve the best performance, we
recommend the following notes.
13.2.1 Space for Cables
Make sure there is enough space for connecting the cables.
80mm minimum clearance for cables
