Technical Specification - CONFIDENTIAL - Page 21 of 21
DESKO ICON Scanner
®
Doc # 7 001 140 101 Doc.-Rev.: 2016-11-09
13.2.2 Extraneous Light
For integration of the ICON Scanner and ICON Scanner
OEM with short cover, a shading for
extraneous light from top and from side is recommended to achieve best image quality.
150mm
13.2.3 RFID Integration
When integrating a ICON Scanner or a ICON Scanner OEM with RFID option, please make
sure there is no metal close to the device. Any metal near to the ICON Scanner with RFID
option detunes the RFID antennas and the RFID reading has no longer the specified
performance.
Metal environment (red marked)
If you want to integrate a ICON Scanner with RFID option in a metal environment, please
contact your DESKO contact person to discuss special integration rules.
45mm
