6159924330 - 08/2020 - 5 -
Two conditions are required to release the tool:
- the tool must receive a "RESET" signal from the PLC (min. duration: 10 ms)
- the eSTOP button must be pressed again.
The message will then disappear from the screen and the tool will be ready to use again.
The eSTOP signal is available on the I/O 24V, Fieldbus and eBUS.
CVI3 Function eSTOP 6159326930
CVI3 Vision eSTOP 6159326940
TWINCVI3 eSTOP 6159326980
eSTOP controllers cables
Always make sure to use the cables supplied with the controller.
Description Length (m) Length (ft) Part number
Cable - 2 M8 male plugs 0.5 1.64 6159176260
Cable - 2 M8 male plugs 1 3.28 6159176330
Cable - 2 M8 male plugs 2 6.56 6159176340
Cable - 2 M8 male plugs 5 16.40 6159176350
Terminal plugs kit - - 6159176075
ePOD
ePOD1 enables to have a complete backup of the controller configuration.
ePOD2 enables to have or activate:
A complete backup of the configuration.
An increased storage of results, curves, events.
Advanced features such as advanced tightening strategies (seating detection and zero torque angle), the man-
agement of positioning arms without any extra device.
Desoutter protocol.
CVILOGIX (Embedded PLC of CVI3 controllers).
ePOD2 eCompass enables to activate eCompass support for EAD20-1300/EAD32-900/EAD50-900/EAD70-800.
ePOD3 enables to have or activate:
an increased number of steps in the tightening process (for cord tools)
the "Workgroup" configuration
ePOD2C, ePOD3C, ePOD4C additionally allow to have more cordless tools connected to CVI3 Vision (up to 4
cordless tools maximum with ePOD4C).
ePOD Essential is dedicated to CVI3 Essential controller and enables to have or activate:
A complete backup of the configuration.
An increased storage of results (OK,NOK) and events.
CVILOGIX (Embedded PLC of CVI3 controllers).
ePOD1 6159360750
ePOD2 6159360760
ePOD2 eCompass 6159363330
ePOD3 6159360770
ePOD2C 6159363110
ePOD3C 6159363180
ePOD4C 6159363120
ePOD Essential 6159368360
