17 95-87142.2
3 METERS
MAXIMUM HEIGHT
1 METER
OR BELOW
FROST LINE
NOTE: INSTALLATIONS NEAR MAXIMUM HEIGHT TYPICALLY REQUIRE
BRACING TO ENSURE NO MOVEMENT OF THE LS2000 DETECTOR.
A2666
IMMOVABLE
STRUCTURE
Figure 6—Example of Bracing Added to Vertical Mounting Poles for Increased Robustness of LS2000 Installation
Figure 7—LS2000 Gas Detector Mounted to Vertical Post
Figure 8—LS2000 Gas Detector Mounted to Flat Surface
(Refer to "Dimensions" in the SPECIFICATIONS section for
mounting plate hole spacing dimensions.)
