3300-0192-0M Rev D 01/17 1
SPECIFICATIONS
Capacity: 600 lb x 0.2 lb / 1,000 lb x 0.5 lb
300 kg x 0.1 kg / 500 kg x 0.2 kg
Weighing/Height Units: Pounds/Inch (lb, in) or Kilograms/Centimeters (kg, cm)
Platform Size: 17 in W x 17 in D x 1.5 in H
(43 cm W x 43 cm D x 3.8 cm D)
Overall Dimensions: 17 in W x 18.5 in D x 88.5 in H
(43 cm W x 47 cm D x 224.8 cm H)
Sonar Height Rod Measures: 24” (2’) – 86” (7’2”) x 0.2 in
(60 cm – 218 cm) x 0.5 cm
Display Type: 3.2 in (diagonal) full color TFT display
320x240 resolution
Number of Characters: Weight: 5 digit, 0.8 in (20 mm) high
Height: 4 digit, 0.35 in (9 mm) high
BMI: 3 digit, 0.35 in (9 mm) high
Touch Screen: Resistive touch panel covering the display
Keys: Mechanical switch type, Power, Zero, Lock/Release, ID,
Cycle Display Mode, Menu, Print
Power Requirements: Included 100 to 240 VAC 50/60Hz 12 VDC 1A wall plug-in
UL/CSA listed AC power adapter (Cardinal part number
6800-1045) or optional 12 “AA” cell Alkaline, Ni-Cad or NiMH
batteries (not included)
Operating Environment:
Operated Temperature Range: 14 to 104 ºF (-10 to +40 ºC)
Humidity: 0 to 90% non-condensing
Communication Interfaces: RS232, USB
Standard Features:
Dual Range Weight
1 RS232 Serial Port
Auto Weight Lock Feature
1 USB-B Port
StableSENSE
® 1
Adjustable Filtering
Sonar Height Rod
8-Digit Numeric Patient ID
Optional Features:
Wi-Fi
WAConnect, Welch Allyn
®
Interface
Bluetooth
1
StableSENSE
®
is a digital filter utilizing proprietary software algorithms to remove or greatly
reduce changes in the weight display resulting from movement on the scale platform.
StableSENSE
®
can be used with clinical scales to lessen the effects of the patient’s
movement or vibration on the scale. Any application affected by vibration or movement on
the scale platform can benefit using StableSENSE
®
.
