3300-0192-0M Rev D 01/17 11
ANNUNCIATORS
The annunciators are displayed on the Weight screen to show that the scale is in the mode
corresponding to the annunciator label or that the status indicated by the label is active.
WEIGHT: POUNDS/GROSS AC
CENTER ZERO
0.0
HEIGHT: IN BMI
0.0 0.0
AC
This is shown on the Weight screen to indicate that the scale is powered by the AC adapter.
##
This is shown on the Weight screen to indicate that the scale is powered by batteries and
the percentage of their remaining charge.
POUNDS/GROSS
This is shown on the Weight screen to indicate that the weight displayed is gross weight in
pounds.
KILOGRAMS/GROSS
This is shown on the Weight screen to indicate that the weight displayed is gross weight in
kilograms.
CENTER ZERO
This is shown on the Weight screen to indicate that the weight is within +/- 1/4 division of the
center of zero.
LOCK
This is shown on the Weight screen to indicate that the scale is locked onto the displayed
weight. In operation after obtaining a stable weight value, pressing the
key will cause
the scale to lock onto the weight and turn on the annunciator. Pressing the
key a
second time will unlock the display and turn off the annunciator.
IN
This is shown on the Weight screen to indicate that the displayed height measurement is in
inches.
CM
This is shown on the Weight screen to indicate that the displayed height measurement is in
centimeters.
BMI
This is shown on the Weight screen to indicate the calculated body fat (Body Mass Index).
Weight Mode
BMI
Display
Height
Display
Power
Status
(AC or ##)
Weight
Display
Status
Messages
