6
Specific Gravity
in [kg/l]
in [°Bé (degrees Baumé) *]
State of Charge
Normal Tropics Normal Tropics
1.28 1.23 32 27 Fully charged
1.20 1.12 24 16 Half charged, recharge
1.12 1.08 16 11 Discharged, charge up immediately
* Measurement of the specific gravity in °Bé (de-
grees Baumé) is obsolete and rarely used today.
The gases emitted by the battery
are explosive! Avoid formation of
sparks in the vicinity of battery,
keep away any open flames!
Do not allow acid to come into
contact with skin or clothing!
Wear protective goggles!
Do not place tools on battery!
!
Service and Maintenance 6.7 Accessories
6
Notes on the three-phase system:
● When the engine is running, never disconnect
the cables between battery, alternator and
regulator.
● Where it is, however, necessary, to start and
operate the engine without battery, disconnect
the regulator from the alternator before
starting.
● Be sure not to confuse the battery terminals.
● Renew a defective charging pilot light bulb
immediately.
● Engine cleaning: Do not spray with water/
steam jet directly against alternator!
Warm up engine to allow water residues to
evaporate.
● Do no loosen connecting cable between battery
and alternator during engine operation.
● The habit of touching a lead against frame to
check whether it is live must under no
circumstances be applied with a three-phase
electric system.
● In case of electric welding, connect the earth
terminal of the welding unit direct to the part to
be welded.
26 409 0
26 410 0
● For transporting the engine, always use the
proper lifting tackle.
● Remove lifting tackle.
– Do not start engine with lifting tackle fitted.
Always use the proper lifting
tackle!
!
6.7.2 Three-Phase Alternator 6.7.3 Lifting Tackle
6.7 Accessories Service and Maintenance
1
2
