Deutz 1015 - Cyl. Bank B BF6 M 1015; Cyl. Bank a BF8 M 1015

2
26 393 0
16
17
181920
21
22
23
2.2.2 Cyl. Bank B – BF6M1015
16 Charge air pipe
17 Oil dipstick
18 Oil drain plug
19 SAE housing
20 Flywheel
21 Exhaust turbocharger
22 Injection pump
23 Flame-type heater plug (A-side)
2.2 Engine Illustration Description of Engine
2
26 412 0
2.2.3 Cyl. Bank A – BF8M 1015
1 Exhaust turbocharger
2 Exhaust manifold
3 Crankcase
4 Starter
5 Oil filler neck
6 Oil pan
7 Lube oil filter
8 V-belt pulley with vibration damper
9 Coolant connection from heat exchanger to
engine
10 Oil cooler
11 Fan
12 Exhaust stack
13 Charge air pipe to the charge air cooler
14 Flame-type heater plug system (B-side)
Description of Engine 2.2 Engine Illustration
1
2
3
4
5678
9
10
11
12
13
14
