dS2824 User Manual v4.12
TCP/IP command sets
There are four TCP/IP command sets on four selectable check boxes, of which one or none
may be selected on the TCP/IP config tab. These are ASCII, Modbus, Binary and Binary with
AES256 encryption.
ASCII command set
The ASCII command set allows you to type commands using a TCP/IP terminal program such
as PuTTY. Use PuTTy in raw mode.
Make sure you have you module set to ASCII mode and, after the “update Pending” indicator
has gone out, re-booted the module so the changes take effect.
ASCII commands are all two character commands and are not case sensitive. Type ST followed
by the return key. This is the STatus command. You will see:
Copyright © 2016-2021, Devantech Ltd.
All rights reserved.
www.robot-electronics.co.uk
51
