Graphic symbols used on this machine
These are some of major exemplary graphical symbols.
Graphic
symbols
Descriptions Graphic
symbols
Descriptions
"ON" position "OFF" position
STAND-BY push-push type switches
Ground/Earth (Protective bonding ter-
minal)
Ground/Earth (Protective earthing)
CLASS II EQUIPMENT Class II equipment with functional
earthing
Functional earthing General precaution
High temperature Electrical shock hazard
CAUTION
moving fan blade
CAUTION
DOUBLE POLE / NEUTRAL FUSING
