Deviser DS2400Q User Manual

DS2400Q QAM Analyzer Operation Manual
DEVISER 55 DS2400Q
3.9.1 Soft Keys Operation
50Hz/60Hz( ):After pressing 50Hz or 60Hz
soft key, the DS2400Q will select the frequency of
system power as figure 3-9-2.
Figure 3-9-2
or are used to switch analogue
channels circularly. Also you can input the channel
number using the character/digit keys.
SAVE ( ):Press SAVE soft key and enter into
Figure 3-13-2 to save the result of tilt test ,refer to
3.13.2.
